| Вход |
Input voltage 220 V AC / 230 V AC / 240 V AC, Voltage range without battery mode 176 – 276 V AC, Mains current (system reaction) λ ≥0.98, Current consumption at nominal load (max.) 31 A |
| Изход |
Rated output voltage (adjustable) 220 V AC / 230 V AC / 240 V AC ±1 %, Output current (at 230 V AC) 26 A , Transfer time at mains outage 0 ms (without interruption), Voltage waveform Sinusoidal, distortion THD <4 %, Overload response (online operation) < |
| Честота |
Output - Frequency in battery mode 50 Hz / 60 Hz ±0.1 %, Input - (auto selection) 50 Hz / 60 Hz ±4 Hz |
| Портове за управление |
Interfaces RS232 (with status display and data), communications slot for SNMP, potential free relay contact, Shutdown software (on CD) 5 network licenses for all common OS (e.g. Windows, Linux, Mac), Failure indicators (acoustic / visual) LED display for |
| Батерия |
Type Sealed, maintenance free, integrated (proprietary brand), Rated voltage (linked) 240 V DC, Overload / deep discharge protection Yes, Charging time (to 90 % rated capacity) 7 h |
| Мощност |
6000 VA 4200 W Parallel connection |
| Размер |
W x H x D (mm) UPS 260 x 720 x 570, Dimensions approx. W x H x D (mm) battery Integrated (not S-version battery pack same dimensions as UPS) |
| Тегло (нето) |
Weight approx. UPS 90 kg, Weight approx. battery 65 kg |
| Други |
Efficiency AC – AC (at nominal load) ≥90 %, Audible noise (1 m distance) <55 dB(A) |
| Гаранционен срок |
24 месеца |
