| Чипсет |
Northbridge: AMD 760G, Southbridge: AMD SB710 |
| Съвместими процесори |
Support for Socket AM3+ processors, Support for Socket AM3 processors: AMD Phenom II X6 / X4 / X3 / X2 (except 920 / 940) / Athlon II X4 / X3 / X2 / Sempron processors, Supports 8-Core CPU |
| Памет |
Dual Channel DDR3 memory technology, 2 x DDR3 DIMM slots, Supports DDR3 1866(OC)/1600(OC)/1333/1066 non-ECC, un-buffered memory, Max. capacity of system memory: 16GB* |
| Портове |
1 x PS/2 Mouse Port, 1 x PS/2 Keyboard Port, 1 x VGA Port, 4 x Ready-to-Use USB 2.0 Ports, 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED), HD Audio Jack: Line in / Front Speaker / Microphone |
| Слотове |
1 x PCI Express 2.0 x16 slot (PCIE1 @ x16 mode) , 1 x PCI slot |
| Видео |
Integrated AMD Radeon 3000 graphics, DX10 class iGPU, Pixel Shader 4.0, Max. shared memory 512MB, Supports D-Sub with max. resolution up to 2048x1536 @ 60Hz |
| Аудио |
5.1 CH HD Audio (Realtek ALC662 Audio Codec) |
| LAN |
PCIE x1 Gigabit LAN 10/100/1000 Mb/s, Atheros AR8151, Supports Wake-On-LAN, Supports PXE |
| BIOS |
8Mb AMI Legal BIOS, Supports "Plug and Play", ACPI 1.1 Compliance Wake Up Events, Supports jumperfree, SMBIOS 2.3.1 Support, CPU, VCCM, NB Voltage Multi-adjustment |
| Форм фактор |
Micro ATX Form Factor, Solid Capacitor for CPU power |
| Аксесоари |
Quick Installation Guide, Support CD, I/O Shield - 2 x SATA Data Cables |
| Гаранционен срок |
24 месеца |
