Характеристики
Характеристики
| Чипсет | Northbridge: AMD 970, Southbridge: AMD SB950 |
|---|---|
| Съвместими процесори | Supports Socket AM3+ processors, Supports Socket AM3 processors: AMD Phenom II X6 / X4 / X3 / X2 (except 920 / 940) / Athlon II X4 / X3 / X2 / Sempron processors, Supports 8-Core CPU, Supports UCC feature (Unlock CPU Core), Digi Power design, 8 + 2 Power |
| Памет | Dual Channel DDR3 Memory Technology, 4 x DDR3 DIMM Slots, Supports DDR3 2400+(OC)/2100(OC)/1866(OC)/1800(OC)/1600(OC)/1333/1066 non-ECC, un-buffered memory, Max. capacity of system memory: 64GB, Supports Intel Extreme Memory Profile (XMP) 1.3 / 1.2, Suppo |
| Портове | 1 x PS/2 Mouse Port, 1 x PS/2 Keyboard Port, 1 x Optical SPDIF Out Port, 4 x USB 2.0 Ports, 1 x USB 3.1 Type-A Port (10 Gb/s), 1 x USB 3.1 Type-C Port (10 Gb/s), 2 x USB 3.0 Ports, 1 x RJ-45 LAN Port with LED, HD Audio Jacks: Rear Speaker / Central / Bass |
| Слотове | 1 x PCI Express 2.0 x16 Slot (PCIE2: x16 mode), 1 x PCI Express 2.0 x16 Slot (PCIE4: x4 mode), 2 x PCI Express 2.0 x1 Slots, 1 x PCI Slot, Supports AMD Quad CrossFireX and CrossFireX |
| Конектори | 1 x COM Port Header; 1 x Power LED Header; 2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin); 4 x Chassis Fan Connectors (2 x 4-pin, 2 x 3-pin); 1 x 24 pin ATX Power Connector; 1 x 8 pin 12V Power Connector; 1 x Front Panel Audio Connector; 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)); 1 x USB 3.0 Header by Etron EJ188H (Supports 2 USB 3.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) |
| Дисков интерфейс | 6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5 and RAID 10), NCQ, AHCI and Hot Plug, 1 x M.2_SSD (NGFF) Socket 3, supports type 2230/2242/2260/2280/22110 M.2 PCI Express module up to Gen2 x4 (20 Gb/s) |
| Видео | n/a |
| Аудио | 7.1 CH HD Audio with Content Protection (Realtek ALC1150 Audio Codec), Premium Blu-ray Audio support, Supports Surge Protection (ASRock Full Spike Protection), ELNA Audio Caps, Supports DTS Connect |
| LAN | PCIE x1 Gigabit LAN 10/100/1000 Mb/s, Realtek RTL8111GR, Supports Wake-On-WAN, Supports Wake-On-LAN, Supports Lightning/ESD Protection (ASRock Full Spike Protection), Supports LAN Cable Detection, Supports Energy Efficient Ethernet 802.3az, Supports PXE |
| BIOS | 32Mb AMI UEFI Legal BIOS with GUI support, Supports "Plug and Play", ACPI 1.1 Compliant wake up events, Supports jumperfree, SMBIOS 2.3.1 support, CPU, VCCM, NB, SB Voltage multi-adjustment |
| Форм фактор | ATX Form Factor, Solid Capacitor design |
| Аксесоари | Quick Installation Guide, Support CD, I/O Shield; 2 x SATA Data Cables; 1 x Screw for M.2 Socket |
| Гаранционен срок | 36 месеца |
