| Чипсет |
Intel B75; Supports Intel Small Business Advantage; Supports Intel Rapid Start Technology and Smart Connect Technology |
| Процесор |
Supports 3rd and 2nd Generation Intel Core i7 / i5 / i3 / Xeon / Pentium / Celeron in LGA1155 Package; Digi Power Design; 4 + 2 Power Phase Design |
| Съвместими процесори |
Supports Intel Turbo Boost 2.0 Technology; Supports Hyper-Threading Technology |
| Памет |
Dual Channel DDR3 memory technology; 2 x DDR3 DIMM slots; Supports DDR3 2200(OC)***/1600/1333/1066 non-ECC, un-buffered memory; Max. capacity of system memory: 16GB* Supports Intel® Extreme Memory Profile (XMP) 1.3 / 1.2 |
| Портове |
1 x PS/2 Keyboard Port; 1 x D-Sub Port; 1 x DVI-D Port; 1 x HDMI Port; 1 x Optical SPDIF Out Port; 4 x Ready-to-Use USB 2.0 Ports; 1 x eSATA2 Connector; 2 x Ready-to-Use USB 3.0 Ports; 1 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED LED) |
| Слотове |
1 x PCI Express 3.0 x16 slot (PCIE1: x16 mode) |
| Видео |
Supports Intel HD Graphics Built-in Visuals : Intel Quick Sync Video 2.0, Intel InTru 3D, Intel Clear Video HD Technology, Intel Insider, Intel HD Graphics 2500/4000 with Intel Ivy Bridge CPU |
| Аудио |
7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec); Premium Blu-ray audio support |
| LAN |
PCIE x1 Gigabit LAN 10/100/1000 Mb/s; Realtek RTL8111E; Supports Wake-On-LAN; Supports LAN Cable Detection; Supports Energy Efficient Ethernet 802.3az |
| BIOS |
64Mb AMI UEFI Legal BIOS with GUI support; Supports "Plug and Play"; ACPI 1.1 Compliance Wake Up Events; Supports jumperfree; SMBIOS 2.3.1 Support; CPU Core, IGPU, DRAM, 1.8V PLL, VTT, VCCSA Voltage Multi-adjustment |
| Форм фактор |
Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm |
| Гаранционен срок |
24 месеца |
