Характеристики
Характеристики
| Чипсет | Intel B85 |
|---|---|
| Процесор | Supports New 4th and 4th Generation Intel Core i7/i5/i3/Xeon/Pentium/Celeron Processors (Socket 1150) Digi Power design, 4 Power Phase design, Supports Intel Turbo Boost 2.0 Technology |
| Памет | Dual Channel DDR3 Memory Technology, 4 x DDR3 DIMM Slots, Supports DDR3 1600/1333/1066 non-ECC, un-buffered memory, Max. capacity of system memory: 32GB, Supports Intel Extreme Memory Profile (XMP) 1.3 / 1.2 |
| Портове | PS/2 Mouse Port, PS/2 Keyboard Port, D-Sub Port, DVI-D Port, HDMI Port, 4 x USB 2.0 Ports (Supports ESD Protection (ASRock Full Spike Protection)), 2 x USB 3.0 Ports (Supports ESD Protection (ASRock Full Spike Protection)), RJ-45 LAN Port with LED |
| Слотове | 1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode), 5 x PCI Express 2.0 x1 Slots |
| Конектори | 1 x TPM Header, 1 x Power LED Header, 2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin), 2 x Chassis Fan Connectors (1 x 4-pin, 1 x 3-pin), 1 x Power Fan Connector (3-pin), 1 x 24 pin ATX Power Connector, 1 x 8 pin 12V Power Connector, 1 x PCIe Power Connector, 1 x Front Panel Audio Connector, 1 x SPDIF Out Connector, 2 x USB 2.0 Headers, 1 x USB 3.0 Header |
| Дисков интерфейс | 4 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and Hot Plug, 2 x SATA2 3.0 Gb/s Connectors, support NCQ, AHCI and Hot Plug |
| Видео | Supports Intel HD Graphics Built-in Visuals: Intel Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW Encode1, Intel InTru 3D, Intel Clear Video HD Technology, Intel Insider, Intel HD Graphics 4400/4600 Pixel Shader 5.0, DirectX 11.1 |
| Аудио | 5.1 CH HD Audio (Realtek ALC662 Audio Codec), Supports Surge Protection (ASRock Full Spike Protection), ELNA Audio Caps |
| LAN | PCIE x1 Gigabit LAN 10/100/1000 Mb/s, Realtek RTL8111GR, Supports Wake-On-WAN, Supports Wake-On-LAN, Supports Lightning/ESD Protection (ASRock Full Spike Protection), Supports LAN Cable Detection, Supports Energy Efficient Ethernet 802.3az, Supports PXE |
| BIOS | 32Mb AMI UEFI Legal BIOS with multilingual GUI support, ACPI 1.1 Compliant wake up events, SMBIOS 2.3.1 support, CPU, DRAM, PCH 1.05V Voltage multi-adjustment |
| Форм фактор | ATX Form Factor, Solid Capacitor design, High Density Glass Fabric PCB |
| Аксесоари | Quick Installation Guide, Support CD, I/O Shield, 2 x SATA Data Cables |
| Гаранционен срок | 36 месеца |
