| Чипсет |
Intel B85 |
| Съвместими процесори |
Supports 4th Generation Intel Core i7 / i5 / i3 / Xeon / Pentium / Celeron in LGA1150 Package; 4 Power Phase Design; Supports Intel Turbo Boost 2.0 Technology |
| Памет |
Dual Channel DDR3 memory technology; 2 x DDR3 DIMM slots; Supports DDR3 1600/1333/1066 non-ECC, un-buffered memory; Max. capacity of system memory: 16GB*; Supports Intel® Extreme Memory Profile (XMP) 1.3 / 1.2 |
| Портове |
1 x PS/2 Mouse Port; 1 x PS/2 Keyboard Port; 1 x D-Sub Port; 1 x DVI-D Port; 1 x HDMI Port; 4 x USB 2.0 Ports; 2 x USB 3.0 Ports; 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED); HD Audio Jack: Line in / Front Speaker / Microphone |
| Слотове |
1 x PCI Express 3.0 x16 slot (PCIE1: x16 mode); 1 x PCI Express 2.0 x1 slot |
| Видео |
Supports Intel HD Graphics Built-in Visuals : Intel Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW Encode1, Intel InTru 3D, Intel Clear Video HD Technology, Intel Insider, Intel HD Graphics 4400/4600; Pixel Shader 5.0, DirectX 11.1; Max. shared m |
| Аудио |
5.1 CH HD Audio (Realtek ALC662 Audio Codec) |
| LAN |
PCIE x1 Gigabit LAN 10/100/1000 Mb/s; Realtek RTL8111G; Supports Wake-On-LAN; Supports LAN Cable Detection; Supports Energy Efficient Ethernet 802.3az; Supports PXE |
| BIOS |
64Mb AMI UEFI Legal BIOS with Multilingual GUI support; ACPI 1.1 Compliance Wake Up Events; SMBIOS 2.3.1 Support; CPU, DRAM, PCH 1.05V, PCH 1.5V Voltage Multi-adjustment |
| Форм фактор |
Micro ATX |
| Гаранционен срок |
24 месеца |
