| Чипсет |
AMD A55 FCH (Hudson-D2) |
| Съвместими процесори |
Supports Socket FM2+ 95W / FM2 100W processors |
| Памет |
Dual Channel DDR3 Memory Technology; 2 x DDR3 DIMM Slots; Supports DDR3 2133/1866/1600/1333/1066 non-ECC, un-buffered memory; Max. capacity of system memory: 32GB; Supports Intel Extreme Memory Profile (XMP) 1.3 / 1.2; Supports AMD Memory Profile (AMP) |
| Портове |
1 x PS/2 Mouse Port; 1 x PS/2 Keyboard Port; 1 x D-Sub Port; 1 x DVI-D Port; 1 x HDMI Port; 6 x USB 2.0 Ports; 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED); HD Audio Jacks: Line in / Front Speaker / Microphone |
| Слотове |
1 x PCI Express 3.0 x16 Slot (PCIE1 @ x16 mode); 1 x PCI Express 2.0 x1 Slot; 1 x PCI Slot; Supports AMD Dual Graphics; PCIE 3.0 is only supported with FM2+ CPU. With FM2 CPU, it only supports PCIE 2.0. |
| Дисков интерфейс |
6 x SATA2 3.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug |
| Видео |
Integrated AMD Radeon HD 8000/7000 series graphics in A-series APU; DirectX 11.1, Pixel Shader 5.6 with FM2+ CPU. DirectX 11, Pixel Shader 5.0 with FM2 CPU.; Max. shared memory 2GB; Multi VGA Output options: D-Sub, DVI-D and HDMI Ports |
| Аудио |
5.1 CH HD Audio (Realtek ALC662 Audio Codec) |
| LAN |
PCIE x1 Gigabit LAN 10/100/1000 Mb/s; Realtek RTL8111E; Supports Wake-On-LAN; Supports LAN Cable Detection; Supports Energy Efficient Ethernet 802.3az; Supports PXE |
| BIOS |
64Mb AMI UEFI Legal BIOS with GUI support; Supports "Plug and Play"; ACPI 1.1 Compliant wake up events; Supports jumperfree; SMBIOS 2.3.1 support; DRAM, CPU Voltage multi-adjustment |
| Форм фактор |
Micro ATX |
| Други |
Dimensions: 9.2-in x 7.2-in, 23.4 cm x 18.3 cm; OS: Microsoft Windows 8.1 32-bit / 8.1 64-bit / 8 32-bit / 8 64-bit / 7 32-bit / 7 64-bit; Certifications: FCC, CE, WHQL; ErP/EuP ready (ErP/EuP ready power supply is required) |
| Гаранционен срок |
24 месеца |
