| Чипсет |
AMD A75 FCH (Hudson-D3) |
| Процесор |
Supports Socket FM2+ 95W / FM2 100W processors, 4 + 2 Power Phase design |
| Памет |
64GB, Dual Channel DDR3 Memory Technology, 4 x DDR3 DIMM Slots |
| Multi-GPU Support |
Supports DDR3 2600+(OC)/2400(OC)/2133/1866/1600/1333/1066 non-ECC, un-buffered memory DDR3 2600+ is only supported with two DIMMs., Supports Intel® Extreme Memory Profile (XMP) 1.3 / 1.2, Supports AMD Memory Profile (AMP) |
| Портове |
1 x PS/2 Mouse/Keyboard Port, 1 x D-Sub Port, 1 x DVI-D Port, 1 x HDMI Port, 1 x Optical SPDIF Out Port, 6 x USB 2.0 Ports, 1 x eSATA Connector, 2 x USB 3.0 Ports (AMD A75 FCH (Hudson-D3)), 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) |
| Слотове |
1 x PCI Express 3.0 x16 Slot (PCIE2 @ x16 mode), 1 x PCI Express 2.0 x16 Slot (PCIE4 @ x4 mode), 2 x PCI Express 2.0 x1 Slots, 3 x PCI Slots, Supports AMD Quad CrossFireX, CrossFireX and Dual Graphics, PCIE 3.0 is only supported with FM2+ CPU. With FM2 CP |
| Дисков интерфейс |
5 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug |
| Видео |
Integrated AMD Radeon HD 8000/7000 series graphics in A-series APU, DirectX 11.1, Pixel Shader 5.6 with FM2+ CPU. DirectX 11, Pixel Shader 5.0 with FM2 CPU., Max. shared memory 2GB, Multi VGA Output options: D-Sub, DVI-D and HDMI Ports |
| Аудио |
7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec), Premium Blu-ray Audio support, TI NE5532 Premium Headset Amplifier (Supports up to 600 ohm headsets) |
| LAN |
PCIE x1 Gigabit LAN 10/100/1000 Mb/s, Qualcomm Atheros AR8171, Supports Qualcomm Atheros Security Wake On Internet Technology, Supports Wake-On-LAN, Supports Energy Efficient Ethernet 802.3az |
| BIOS |
64Mb AMI UEFI Legal BIOS with GUI support, Supports "Plug and Play", ACPI 1.1 Compliant wake up events, Supports jumperfree, SMBIOS 2.3.1 support, DRAM, VDDP, VDDR Voltage multi-adjustment |
| Форм фактор |
ATX Form Factor, All Solid Capacitor design |
| Други |
Certifications - FCC, CE, WHQL, ErP/EuP ready (ErP/EuP ready power supply is required) |
| Гаранционен срок |
24 месеца |
