| Чипсет |
AMD A75 FCH (Hudson-D3) |
| Процесор |
Supports Socket FM2+ 95W / FM2 100W processors |
| Памет |
32GB, Dual Channel DDR3 Memory Technology, 2 x DDR3 DIMM Slots, Supports DDR3 2133/1866/1600/1333/1066 non-ECC, un-buffered memory, Supports Intel® Extreme Memory Profile (XMP) 1.3 / 1.2, Supports AMD Memory Profile (AMP) |
| Портове |
1 x PS/2 Mouse Port, 1 x PS/2 Keyboard Port, 1 x D-Sub Port, 1 x DVI-D Port, 1 x HDMI Port, 4 x USB 2.0 Ports, 2 x USB 3.0 Ports (AMD A75 FCH (Hudson-D3)), 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED), HD Audio Jacks: Line in / Front Speaker |
| Слотове |
1 x PCI Express 3.0 x16 Slot (PCIE1 @ x16 mode), 1 x PCI Express 2.0 x1 Slot, 1 x PCI Slot, Supports AMD Dual Graphics |
| Дисков интерфейс |
6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug |
| Видео |
Integrated AMD Radeon R7/R5 Series Graphics in A-series APU, DirectX 11.1, Pixel Shader 5.0 with FM2+ CPU. DirectX 11, Pixel Shader 5.0 with FM2 CPU., Max. shared memory 2GB, Three graphics output options: D-Sub, DVI-D and HDMI, Supports Triple Monitor |
| Аудио |
5.1 CH HD Audio (Realtek ALC662 Audio Codec) |
| LAN |
PCIE x1 Gigabit LAN 10/100/1000 Mb/s, Realtek RTL8111E, Supports Wake-On-LAN, Supports LAN Cable Detection, Supports Energy Efficient Ethernet 802.3az, Supports PXE |
| BIOS |
64Mb AMI UEFI Legal BIOS with GUI support, Supports "Plug and Play", ACPI 1.1 Compliant wake up events, Supports jumperfree, SMBIOS 2.3.1 support, DRAM, CPU Voltage multi-adjustment |
| Форм фактор |
Micro ATX Form Factor: 23.4 cm x 18.3 cm |
| Други |
OS: Microsoft Windows 8.1 32-bit / 8.1 64-bit / 8 32-bit / 8 64-bit / 7 32-bit / 7 64-bit 8.1 32-bit / 8.1 64-bit / 8 32-bit / 8 64-bit / 7 32-bit / 7 64-bit |
| Гаранционен срок |
24 месеца |
