| Чипсет |
Intel H61; Supports Intel Rapid Start Technology and Smart Connect Technology |
| Процесор |
Supports 3rd and 2nd Generation Intel Core i7 / i5 / i3 / Xeon / Pentium / Celeron in LGA1155 Package |
| Съвместими процесори |
Supports Intel Turbo Boost 2.0 Technology; Supports Intel K-Series CPU; Supports Hyper-Threading Technology |
| Памет |
Dual Channel DDR3 memory technology; 2 x DDR3 DIMM slots; Supports DDR3 1600/1333/1066 non-ECC, un-buffered memory; Max. capacity of system memory: 16GB*; Supports Intel Extreme Memory Profile (XMP) 1.3 / 1.2 with Intel Ivy Bridge CPU |
| Портове |
1 x PS/2 Mouse Port; 1 x PS/2 Keyboard Port; 1 x Serial Port: COM1; 1 x Parallel Port (ECP/EPP support); 1 x D-Sub Port; 4 x USB 2.0 Ports; 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED); HD Audio Jack: Line in / Front Speaker / Microphone |
| Слотове |
1 x PCI Express 3.0 x16 slot (blue @ x16 mode); 1 x PCI Express 2.0 x1 slot |
| Видео |
Supports Intel HD Graphics Built-in Visuals : Intel Quick Sync Video 2.0, Intel InTru 3D, Intel Clear Video HD Technology, Intel Insider, Intel HD Graphics 2500/4000 with Intel Ivy Bridge CPU |
| Аудио |
5.1 CH HD Audio (Realtek ALC662 Audio Codec) |
| LAN |
PCIE x1 Gigabit LAN 10/100/1000 Mb/s; Realtek RTL8111E; Supports Wake-On-LAN; Supports LAN Cable Detection; Supports Energy Efficient Ethernet 802.3az; Supports PXE |
| BIOS |
32Mb AMI UEFI Legal BIOS with GUI support; Supports "Plug and Play"; ACPI 1.1 Compliance Wake Up Events; Supports jumperfree; SMBIOS 2.3.1 Support |
| Форм фактор |
Micro ATX Form Factor |
| Гаранционен срок |
24 месеца |
