| Чипсет |
Intel H81 |
| Съвместими процесори |
Supports 4th generation Intel Core i7 / i5 / i3 / Xeon / Pentium / Celeron in LGA1150 package; 4 Power Phase design; Supports Intel Turbo Boost 2.0 Technology |
| Памет |
Dual Channel DDR3 Memory Technology; 2 x DDR3 DIMM Slots; ; Supports DDR3 1600/1333/1066 non-ECC, un-buffered memory; Max. capacity of system memory: 16GB; Supports Intel Extreme Memory Profile (XMP) 1.3 / 1.2 |
| Портове |
1 x PS/2 Mouse/Keyboard Port; 1 x D-Sub Port; 1 x DVI-D Port; 1 x HDMI Port; 1 x Optical SPDIF Out Port; 1 x eSATA Connector; 4 x USB 2.0 Ports; 2 x USB 3.0 Ports; 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) |
| Слотове |
1 x PCI Express 2.0 x16 Slot |
| Дисков интерфейс |
2 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and Hot Plug; 1 x eSATA Connector, supports NCQ, AHCI and Hot Plug |
| Видео |
Supports Intel HD Graphics Built-in Visuals : Intel Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW Encode1, Intel InTru 3D, Intel Clear Video HD Technology, Intel Insider, Intel HD Graphics 4400/4600; Pixel Shader 5.0, DirectX 11.1 |
| Аудио |
7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec); Premium Blu-ray Audio support |
| LAN |
PCIE x1 Gigabit LAN 10/100/1000 Mb/s; Qualcomm Atheros AR8171; aSupports Qualcomm Atheros Security Wake On Internet Technology; Supports Wake-On-LAN; Supports Energy Efficient Ethernet 802.3az; Supports PXE |
| BIOS |
32Mb AMI UEFI Legal BIOS with multilingual GUI support; ACPI 1.1 compliance wake up events; SMBIOS 2.3.1 support; CPU, DRAM, PCH 1.05V, PCH 1.5V Voltage multi-adjustment |
| Форм фактор |
Mini-ITX; All Solid Capacitor design |
| Други |
OS: Microsoft Windows 8 / 8 64-bit / 7 / 7 64-bit compliant; Certifications: FCC, CE, WHQL; ErP/EuP ready (ErP/EuP ready power supply is required) |
| Гаранционен срок |
24 месеца |
