| Чипсет |
Intel H87 |
| Съвместими процесори |
Supports 4th Generation Intel Core i7 / i5 / i3 / Xeon / Pentium / Celeron in LGA1150 Package, Digi Power Design, 4 Power Phase Design, Supports Intel Turbo Boost 2.0 Technology |
| Памет |
Dual Channel DDR3 memory technology, 4 x DDR3 DIMM slots, Supports DDR3 1600/1333/1066 non-ECC, un-buffered memory, Max. capacity of system memory: 32GB*, Supports Intel Extreme Memory Profile (XMP) 1.3 / 1.2 |
| Портове |
1 x PS/2 Mouse/Keyboard Port, 1 x D-Sub Port, 1 x DVI-D Port, 1 x HDMI Port, 2 x USB 2.0 Ports, 4 x USB 3.0 Ports, 1 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED LED) |
| Слотове |
1 x PCI Express 3.0 x16 slot (PCIE2: x16 mode),3 x PCI Express 2.0 x1 slots,2 x PCI slots |
| Дисков интерфейс |
6 x SATA3 6.0 Gb/s connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology 12 and Intel Smart Response Technology), NCQ, AHCI and Hot Plug |
| Видео |
Supports Intel HD Graphics Built-in Visuals : Intel Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW Encode1, Intel InTru 3D, Intel Clear Video HD Technology, Intel Insider, Intel HD Graphics 4400/4600, Pixel Shader 5.0, DirectX 11.1 |
| Аудио |
7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec), Premium Blu-ray audio support |
| LAN |
Gigabit LAN 10/100/1000 Mb/s, Giga PHY Intel I217V, Supports Intel Remote Wake Technology, Supports Wake-On-LAN, Supports Energy Efficient Ethernet 802.3az, Supports PXE |
| BIOS |
64Mb AMI UEFI Legal BIOS with Multilingual GUI support, ACPI 1.1 Compliance Wake Up Events, SMBIOS 2.3.1 Support, CPU, DRAM, PCH 1.05V Voltage Multi-adjustment |
| Форм фактор |
ATX Form Factor, All Solid Capacitor design |
| Аксесоари |
Quick Installation Guide, Support CD, I/O Shield, 2 x SATA Data Cables |
| Гаранционен срок |
24 месеца |
