| Чипсет |
Intel H87; Supports Intel Small Business Advantage 2.0 |
| Процесор |
Supports 4th Generation Intel Core i7 / i5 / i3 / Xeon / Pentium / Celeron in LGA1150 Package; 4 Power Phase Design |
| Съвместими процесори |
Supports Intel Turbo Boost 2.0 Technology |
| Памет |
Dual Channel DDR3 memory technology; 2 x DDR3 DIMM slots; Supports DDR3 1600/1333/1066 non-ECC, un-buffered memory; Max. capacity of system memory: 16GB; Supports Intel Extreme Memory Profile (XMP) 1.3 / 1.2 |
| Портове |
1 x PS/2 Mouse/Keyboard Port; 1 x D-Sub Port; 1 x DVI-D Port; 1 x HDMI Port; 1 x Optical SPDIF Out Port; 4 x USB 2.0 Ports; 4 x USB 3.0 Ports; 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED); HD Audio Jack: Rear Speaker / Central / Bass / Line in |
| Слотове |
1 x PCI Express 3.0 x16 slot (PCIE1: x16 mode); 1 x PCI Express 2.0 x16 slot (PCIE2: x4 mode); 2 x PCI slots; Supports AMD Quad CrossFireX and CrossFireX |
| Видео |
Supports Intel HD Graphics Built-in Visuals : Intel Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW Encode1, Intel InTru 3D, Intel Clear Video HD Technology, Intel Insider, Intel HD Graphics 4400/4600; Pixel Shader 5.0, DirectX 11.1 |
| Аудио |
7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec); Premium Blu-ray audio support |
| LAN |
PCIE x1 Gigabit LAN 10/100/1000 Mb/s; Qualcomm Atheros AR8171; Supports Qualcomm Atheros Security Wake On Internet Technology; Supports Wake-On-LAN; Supports Energy Efficient Ethernet 802.3az; Supports PXE |
| BIOS |
64Mb AMI UEFI Legal BIOS with Multilingual GUI support; ACPI 1.1 Compliance Wake Up Events; SMBIOS 2.3.1 Support; CPU, DRAM, PCH 1.05V, PCH 1.5V Voltage Multi-adjustment |
| Форм фактор |
Micro ATX |
| Гаранционен срок |
24 месеца |
