| Чипсет |
Intel H97, Supports Intel Small Business Advantage 2.0 |
| Процесор |
- |
| Съвместими процесори |
Supports 5th Generation, New 4th and 4th Generation Intel Xeon/Core i7/i5/i3/Pentium/Celeron Processors (Socket 1150), Digi Power design, 4 Power Phase design, Supports Intel Turbo Boost 2.0 Technology |
| Памет |
Dual Channel DDR3 Memory Technology, 4 x DDR3 DIMM Slots, Supports DDR3 1600/1333/1066 non-ECC, un-buffered memory, Max. capacity of system memory: 32GB*, Supports Intel Extreme Memory Profile (XMP) 1.3 / 1.2 |
| Портове |
1 x PS/2 Mouse/Keyboard Port, 1 x D-Sub Port, 1 x DVI-D Port, 1 x HDMI Port, 2 x USB 2.0 Ports (Supports ESD Protection (ASRock Full Spike Protection)), 4 x USB 3.0 Ports (Supports ESD Protection (ASRock Full Spike Protection)), 1 x RJ-45 LAN Port with LE |
| Слотове |
1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode), 3 x PCI Express 2.0 x1 Slots, 2 x PCI Slots |
| Дисков интерфейс |
6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage Technology 13 and Intel Smart Response Technology), NCQ, AHCI and Hot Plug |
| Видео |
Supports Intel HD Graphics Built-in Visuals: Intel Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW Encode1, Intel InTru 3D, Intel Clear Video HD Technology, Intel Insider, Intel HD Graphics 4400/4600, Pixel Shader 5.0, DirectX 11.1 |
| Аудио |
7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec), Premium Blu-ray Audio support, Supports Surge Protection (ASRock Full Spike Protection), ELNA Audio Caps |
| LAN |
Gigabit LAN 10/100/1000 Mb/s, Giga PHY Intel I218V, Supports Intel Remote Wake Technology, Supports Wake-On-LAN, Supports Lightning/ESD Protection (ASRock Full Spike Protection), Supports Energy Efficient Ethernet 802.3az, Supports PXE |
| BIOS |
128Mb AMI UEFI Legal BIOS with multilingual GUI support, ACPI 1.1 Compliant wake up events, SMBIOS 2.3.1 support, CPU, DRAM, PCH 1.05V, PCH 1.5V Voltage multi-adjustment |
| Форм фактор |
ATX Form Factor,Solid Capacitor design, High Density Glass Fabric PCB |
| Аксесоари |
Quick Installation Guide, Support CD, I/O Shield,2 x SATA Data Cables |
| Гаранционен срок |
24 месеца |
