ASROCK P75 Pro3, B75, LGA1155
Характеристики
Характеристики
| Чипсет | Intel B75; Supports Intel Small Business Advantage; Supports Intel Rapid Start Technology and Smart Connect Technology with Intel Ivy Bridge CPU |
|---|---|
| Съвместими процесори | Supports 3rd and 2nd Generation Intel Core i7 / i5 / i3 in LGA1155 Package; Supports Intel Turbo Boost 2.0 Technology; Supports Hyper-Threading Technology |
| Памет | Dual Channel DDR3 memory technology; 2 x DDR3 DIMM slots; Supports DDR3 2200(OC)/1600/1333/1066 non-ECC, un-buffered memory DDR3 2200(OC) is only supported with Intel Core i7 3770K; Max. capacity of system memory: 16GB |
| Портове | 1 x PS/2 Mouse/Keyboard Port; 1 x Parallel Port (ECP/EPP Support); 1 x Serial Port: COM1; 1 x Coaxial SPDIF Out Port; 4 x Ready-to-Use USB 2.0 Ports; 2 x Ready-to-Use USB 3.0 Ports; 1 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED LED) |
| Слотове | 1 x PCI Express 3.0 x16 slot (PCIE1: x16 mode); 1 x PCI Express 2.0 x16 slot (PCIE3: x4 mode); 2 x PCI Express 2.0 x1 slots; 2 x PCI slots; Supports AMD Quad CrossFireX and CrossFireX |
| Аудио | 7.1 CH HD Audio (Realtek ALC887 Audio Codec) |
| LAN | PCIE x1 Gigabit LAN 10/100/1000 Mb/s; Realtek RTL8111E; Supports Wake-On-LAN; Supports LAN Cable Detection; Supports Energy Efficient Ethernet 802.3az; Supports PXE |
| BIOS | 64Mb AMI UEFI Legal BIOS with GUI support; Supports "Plug and Play"; ACPI 1.1 Compliance Wake Up Events; Supports jumperfree; SMBIOS 2.3.1 Support; CPU Core, DRAM, 1.8V PLL, VTT, VCCSA Voltage Multi-adjustment |
| Форм фактор | ATX |
| Гаранционен срок | 24 месеца |
