Характеристики
Характеристики
| Процесор | Intel Quad-Core Pentium Processor J2900 (2.41 GHz) |
|---|---|
| Памет | Dual Channel DDR3/DDR3L Memory Technology, 2 x DDR3/DDR3L SO-DIMM Slots, Supports DDR3/DDR3L 1333/1066 non-ECC, un-buffered memory, Max. capacity of system memory: 16GB, If only one SO-DIMM module is installed, please install it into DDR3_A1. |
| Портове | PS/2 Mouse Port, PS/2 Keyboard Port, D-Sub Port, DVI-D Port, HDMI Port, Optical SPDIF Out Port, 2 x USB 2.0 Ports (Supports ESD Protection (ASRock Full Spike Protection)), 2 x USB 3.0 Ports (Supports ESD Protection (ASRock Full Spike Protection)), RJ-45 L |
| Слотове | 1 x PCI Express 2.0 x1 Slot, 1 x mini-PCI Express Slot |
| Конектори | 1 x Print Port Header, 1 x COM Port Header, 1 x TPM Header, 1 x Chassis Intrusion Header, 1 x CPU Fan Connector (3-pin), 1 x Chassis Fan Connector (3-pin), 1 x 24 pin ATX Power Connector, 1 x Front Panel Audio Connector, 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)), 1 x USB 3.0 Header by ASMedia ASM1074 (Supports 2 USB 3.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) |
| Дисков интерфейс | 2 x SATA2 3.0 Gb/s Connectors, support NCQ, AHCI and Hot Plug, 2 x SATA3 6.0 Gb/s Connectors by ASMedia ASM1061, support NCQ, AHCI and Hot Plug |
| Видео | Intel 7th generation (Gen 7) graphics, DirectX 11.0, Pixel Shader 5.0, Three graphics output options: D-Sub, DVI-D and HDMI, Supports HDMI Technology with max. resolution up to 1920x1200 @ 60Hz, Supports DVI-D with max. resolution up to 1920x1200 @ 60Hz, |
| Аудио | 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec), Premium Blu-ray Audio support, Supports Surge Protection (ASRock Full Spike Protection) |
| LAN | PCIE x1 Gigabit LAN 10/100/1000 Mb/s, Realtek RTL8111GR, Supports Wake-On-WAN, Supports Wake-On-LAN, Supports Lightning/ESD Protection (ASRock Full Spike Protection), Supports LAN Cable Detection, Supports Energy Efficient Ethernet 802.3az, Supports PXE |
| BIOS | 64Mb AMI UEFI Legal BIOS with GUI support, Supports Plug and Play, ACPI 1.1 compliant wake up events, Supports jumperfree, SMBIOS 2.3.1 support |
| Форм фактор | Mini-ITX Form Factor, All Solid Capacitor design, High Density Glass Fabric PCB |
| Аксесоари | Quick Installation Guide, Support CD, I/O Shield, 2 x SATA Data Cables, 1 x WiFi Module Screw |
| Гаранционен срок | 36 месеца |
