Характеристики
Характеристики
| Чипсет | SOC |
|---|---|
| Процесор | AMD FT3 Kabini A4-5000 Quad-Core APU |
| Памет | 2 x DDR3 DIMM Slots, Supports DDR3 1600/1333/1066 non-ECC, un-buffered memory, Max. capacity of system memory: 32GB |
| Портове | 1 x PS/2 Mouse/Keyboard Port, 1 x D-Sub Port, 1 x DVI-D Port, 1 x HDMI Port, 1 x DisplayPort 1.2, 1 x Optical SPDIF Out Port, 2 x USB 2.0 Ports (Supports ESD Protection (ASRock Full Spike Protection)), 2 x USB 3.0 Ports |
| Слотове | 1 x PCI Express 2.0 x16 Slot (PCIE1 @ x4 mode), 1 x Mini-PCI Express Slot |
| Конектори | 1 x COM Port Header, 1 x TPM Header, 1 x CPU Fan Connector (3-pin), 2 x Chassis Fan Connectors (1 x 4-pin, 1 x 3-pin), 1 x 24 pin ATX Power Connector, 1 x Front Panel Audio Connector, 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)), 1 x USB 3.0 Header by Etron EJ188H (Supports 2 USB 3.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) |
| Дисков интерфейс | 2 x SATA3 6.0 Gb/s Connectors by AMD FT3 Kabini A4-5000 Quad-Core APU, support NCQ, AHCI and Hot Plug, 2 x SATA3 6.0 Gb/s Connectors by ASMedia ASM1061, support NCQ, AHCI and Hot Plug |
| Видео | Integrated AMD Radeon HD 8330 Graphics, DirectX 11.1, Pixel Shader 5.0, Max. shared memory 2GB, Four graphics output options: D-Sub, DVI-D, HDMI and DisplayPort 1.2, Supports HDMI with max. resolution up to 4K x 2K (4096x2160) @ 24Hz or 4K x 2K (3840x2160 |
| Аудио | 7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec), Premium Blu-ray Audio support, Supports Surge Protection (ASRock Full Spike Protection) |
| LAN | PCIE x1 Gigabit LAN 10/100/1000 Mb/s, Realtek RTL8111E, Supports Wake-On-LAN, Supports Lightning/ESD Protection (ASRock Full Spike Protection), Supports LAN Cable Detection, Supports Energy Efficient Ethernet 802.3az, Supports PXE |
| BIOS | 32Mb AMI UEFI Legal BIOS with multilingual GUI support, Supports "Plug and Play", ACPI 1.1 compliance wake up events, SMBIOS 2.3.1 support, DRAM Voltage multi-adjustment |
| Форм фактор | Mini-ITX Form Factor, All Solid Capacitor design, High Density Glass Fabric PCB |
| Аксесоари | Quick Installation Guide, Support CD, I/O Shield, 2 x SATA Data Cables, 1 x WiFi Module Screw |
| Гаранционен срок | 36 месеца |
