| Чипсет |
Intel X79 |
| Съвместими процесори |
Supports Intel Core i7 processor family for the LGA 2011 Socket; Digi Power Design; Advanced 5 + 1 Power Phase Design; Supports Intel Turbo Boost 2.0 Technology; Supports Hyper-Threading Technology; Supports Untied Overclocking Technology |
| Памет |
Quad Channel DDR3 memory technology; 4 x DDR3 DIMM slots; Supports DDR3 2400+(OC)/1600/1333/1066/800 non-ECC, un-buffered memory; Supports DDR3 ECC, un-buffered memory with Intel Workstation 1S Xeon processors E5 16xx/26xx/46xx series in socket LGA 2011; |
| Портове |
1 x PS/2 Mouse Port; 1 x PS/2 Keyboard Port; 1 x Coaxial SPDIF Out Port; 1 x Optical SPDIF Out Port; 6 x Ready-to-Use USB 2.0 Ports; 1 x eSATA3 Connector; 2 x Ready-to-Use USB 3.0 Ports; 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED); 1 x Clear |
| Слотове |
3 x PCI Express 3.0 x16 slots (PCIE1 @ x16 mode; PCIE3 @ x16 mode; PCIE4 @ x8 mode); 1 x PCI Express 2.0 x1 slot; 2 x PCI slots; Supports AMDTM Quad CrossFireX , 3-Way CrossFireX and CrossFireX; Supports NVIDIA Quad SLI , 3-Way SLI and SLI |
| Аудио |
7.1 CH HD Audio with Content Protection (Realtek ALC898 Audio Codec); Premium Blu-ray audio support; Supports THX TruStudio |
| LAN |
PCIE x1 Gigabit LAN 10/100/1000 Mb/s; Broadcom BCM57781; Supports Wake-On-LAN; Supports Energy Efficient Ethernet 802.3az; Supports PXE |
| BIOS |
64Mb AMI UEFI Legal BIOS with GUI support; Supports "Plug and Play"; ACPI 1.1 Compliance Wake Up Events; Supports jumperfree; SMBIOS 2.3.1 Support; CPU, VCCSA, DRAM, VTT, CPU PLL, PCH1.1V, PCH1.5V Voltage Multi-adjustment |
| Форм фактор |
ATX; 30.5 cm x 22.4 cm |
| Гаранционен срок |
24 месеца |
