Характеристики
Характеристики
| Чипсет | Intel X99 |
|---|---|
| Съвместими процесори | Supports Intel Core i7 and Xeon 18-Core Processors Family for the LGA 2011-3 Socket, Digi Power design, 12 Power Phase design, Supports Intel Turbo Boost 2.0 Technology, Supports Untied Overclocking Technology |
| Памет | Quad Channel DDR4 Memory Technology, 8 x DDR4 DIMM Slots, Supports DDR4 3200+(OC)/2933(OC)/2800(OC)/2400(OC)/2133 non-ECC, un-buffered memory, Supports non-ECC RDIMM (Registered DIMM), Supports DDR4 ECC, un-buffered memory/RDIMM with Intel Xeon processors |
| Портове | 1 x PS/2 Mouse/Keyboard Port, 1 x Optical SPDIF Out Port, 1 x eSATA Connector, 2 x USB 2.0 Ports, 1 x USB 3.1 Type-C Port (10 Gb/s) (ASMedia ASM1142), 4 x USB 3.0 Ports (ASMedia ASM1074 hub), 2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED LED), 1 x |
| Слотове | 3 x PCI Express 3.0 x16 Slots (PCIE1 @ x16 mode; PCIE3 @ x16 mode; PCIE5 @ x8 mode), 2 x PCI Express 2.0 x1 Slots, 1 x mini-PCI Express Slot, Supports AMD Quad CrossFireX, 3-Way CrossFireX and CrossFireX, Supports NVIDIA Quad SLI, 3-Way SLI and SLI, 15μ G |
| Конектори | 1 x COM Port Header; 1 x TPM Header; 1 x Power LED Header; 2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin); 3 x Chassis Fan Connectors (1 x 4-pin, 2 x 3-pin) (Smart Fan Speed Control); 1 x Power Fan Connector (3-pin); 1 x 24 pin ATX Power Connector; 1 x 8 pin 12V Power Connector (Hi-Density Power Connector); 1 x HDD Saver Connector; 1 x PCIe Power Connector; 1 x Front Panel Audio Connector; 1 x Thunderbolt™ AIC Connector; 2 x USB 2.0 Headers (support 4 USB 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)); 1 x Vertical Type A USB 2.0; 2 x USB 3.0 Headers (Support 4 USB 3.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)); 1 x Dr. Debug with LED; 1 x Power Switch with LED; 1 x Reset Switch with LED; 1 x BIOS Selection Switch |
| Дисков интерфейс | 10 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10 and Intel® Rapid Storage 13), NCQ, AHCI, Hot Plug and ASRock HDD Saver Technology (SSATA3_3 connector is shared with the eSATA port) (SSATA3_2 connector is shared with Ultra M.2 |
| Видео | n/a |
| Аудио | 7.1 CH HD Audio with Content Protection (Realtek ALC1150 Audio Codec), Premium Blu-ray Audio support, Supports Surge Protection (ASRock Full Spike Protection), Supports Purity Sound 2, Nichicon Fine Gold Series Audio Caps, 115dB SNR DAC with differential |
| LAN | 1 x Intel I218V (Gigabit LAN PHY 10/100/1000 Mb/s), 1 x Qualcomm Atheros AR8171 (PCIE x1 Gigabit LAN 10/100/1000 Mb/s), Supports Qualcomm Atheros Security Wake On Internet Technology (on Qualcomm Atheros AR8171), Supports Wake-On-LAN, Supports Lightning/E |
| BIOS | 2 x 128Mb AMI UEFI Legal BIOS with multilingual GUI support (1 x Main BIOS and 1 x Backup BIOS), Supports Secure Backup UEFI Technology, ACPI 5.0 Compliant wake up events, SMBIOS 2.7 Support, CPU, DRAM, PCH 1.05V, PCH 1.5V, VPPM Voltage Multi-adjustment |
| Форм фактор | ATX Form Factor - 2oz Copper PCB - High Density Glass Fabric PCB, Multiple Filter Cap (MFC) (Filter different noise by 3 different capacitors: DIP solid cap, POSCAP and MLCC) |
| Аксесоари | 1 x ASRock USB 3.1 Card/A+A, 1 x ASRock SLI_Bridge_2S Card, 1 x ASRock 3-Way SLI-2S1S Bridge Card, Quick Installation Guide, Support CD, I/O Shield, 4 x SATA Data Cables, 1 x HDD Saver Cable, 1 x Screw for Ultra M.2 Socket, 1 x Screw for mini-PCIe Slot |
| Други | ASRock USB 3.1, ASRock X Series OC Socket, ASRock Super Alloy, ASRock Ultra M.2 (PCIe Gen3 x4 & SATA3), ASRock HDD Saver Technology, ASRock Full Spike Protection, ASRock APP Shop |
| Гаранционен срок | 36 месеца |
