| Чипсет |
Intel® Z170 |
| Съвместими процесори |
Supports 6th Generation Intel® Core™ i7/i5/i3/Pentium®/Celeron® Processors (Socket 1151); - Digi Power design; - 12 Power Phase design; - Supports Intel® Turbo Boost 2.0 Technology; - Supports Intel® K-Series unlocked CPUs; - Supports ASRock BCLK Full-ran |
| Памет |
Dual Channel DDR4 Memory Technology; - 4 x DDR4 DIMM Slots; - Supports DDR4 3866+(OC)*/3600(OC)/3200(OC)/2933(OC)/2800(OC)/2400(OC)/2133 non-ECC, un-buffered memory * 3866+(OC) memory frequency can only be achieved when a single memory module is installed |
| Портове |
1 x PS/2 Mouse/Keyboard Port; - 1 x DVI-D Port; - 1 x HDMI Port; - 1 x DisplayPort 1.2; - 1 x Optical SPDIF Out Port; - 1 x USB 2.0 Port (Supports ESD Protection (ASRock Full Spike Protection)); - 1 x Fatal1ty Mouse Port (USB 2.0) (Supports ESD Protection |
| Слотове |
4 x PCI Express 3.0 x16 Slots (PCIE2/PCIE4/PCIE6: single at x16 (PCIE2); dual at x8 (PCIE2) / x8 (PCIE4); triple at x8 (PCIE2) / x4 (PCIE4) / x4 (PCIE6). PCIE3: x4 mode)*; - 1 x PCI Express 3.0 x1 Slot (PCIE5) (Flexible PCIe); - 1 x PCI Express 2.0 x1 Slo |
| Конектори |
1 x COM Port Header; - 1 x TPM Header; - 1 x Power LED and Speaker Header; - 2 x CPU Fan Connectors (4-pin) (Smart Fan Speed Control); - 4 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control); - 1 x 24 pin ATX Power Connector; - 1 x 8 pin 12V Power Connector (Hi-Density Power Connector); - 1 x Front Panel Audio Connector; - 1 x Thunderbolt™ AIC Connector; - 3 x USB 2.0 Headers (Support 6 USB 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)); - 2 x USB 3.0 Headers (Support 4 USB 3.0 ports) (ASMedia ASM1074 hub) (Supports ESD Protection (ASRock Full Spike Protection)); - 1 x Dr. Debug with LED; - 1 x Power Switch with LED; - 1 x Reset Switch with LED; - 1 x Clear CMOS Switch; - 1 x BIOS Selection Switch |
| Дисков интерфейс |
6 x SATA3 6.0 Gb/s Connectors by Intel® Z170, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel® Rapid Storage Technology 14 and Intel® Smart Response Technology), NCQ, AHCI and Hot Plug; - 4 x SATA3 6.0 Gb/s Connectors by ASMedia ASM1061, support NCQ, |
| Видео |
Supports Intel® HD Graphics Built-in Visuals : Intel® Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW Encode1, Intel® InTru™ 3D, Intel® Clear Video HD Technology, Intel® Insider™, Intel® HD Graphics 510/530; - Pixel Shader 5.0, DirectX 12; - Max. |
| Аудио |
7.1 CH HD Audio with Content Protection (Realtek ALC1150 Audio Codec); - Premium Blu-ray Audio support; - Supports Surge Protection (ASRock Full Spike Protection); - Supports Purity Sound™ 3; - Nichicon Fine Gold Series Audio Caps; - 115dB SNR DAC with di |
| LAN |
Gigabit LAN 10/100/1000 Mb/s; - 1 x Giga PHY Intel® I219V, 1 x GigaLAN Intel® I211AT; - Supports Wake-On-LAN; - Supports Lightning/ESD Protection (ASRock Full Spike Protection); - Supports Dual LAN with Teaming; - Supports Energy Efficient Ethernet 802.3a |
| BIOS |
2 x 128Mb AMI UEFI Legal BIOS with multilingual GUI support (1 x Main BIOS and 1 x Backup BIOS); - Supports Secure Backup UEFI Technology; - ACPI 5.0 Compliant wake up events; - SMBIOS 2.7 Support; - CPU, GT_CPU, DRAM, VPPM, PCH 1.0V, VCCIO, VCCPLL, VCCSA |
| Форм фактор |
ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm |
| Други |
Microsoft® Windows® 10 64-bit / 8.1 64-bit / 7 32-bit / 7 64-bit |
| Гаранционен срок |
36 месеца |
