| Чипсет |
Intel Z77; Supports Intel Rapid Start Technology and Smart Connect Technology |
| Съвместими процесори |
Supports 3rd and 2nd Generation Intel Core i7 / i5 / i3 in LGA1155 Package; Digi Power Design; 8 + 3 Power Phase Design; Supports Intel Turbo Boost 2.0 Technology; Supports Intel K-Series unlocked CPU; Supports Hyper-Threading Technology |
| Памет |
Dual Channel DDR3 memory technology; 4 x DDR3 DIMM slots; Supports DDR3 2800+(OC)/2400(OC)/2133(OC)/1866(OC)/1600/1333/1066 non-ECC, un-buffered memory; Max. capacity of system memory: 32GB; Supports Intel® Extreme Memory Profile (XMP) 1.3 / 1.2 |
| Портове |
1 x PS/2 Keyboard Port; 1 x D-Sub Port; 1 x DVI-D Port; 1 x HDMI Port; 1 x Optical SPDIF Out Port; 4 x Ready-to-Use USB 2.0 Ports; 2 x Ready-to-Use USB 3.0 Ports; 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED); HD Audio Jack: Rear Speaker / Cent |
| Слотове |
2 x PCI Express 3.0 x16 slots (PCIE2/PCIE3: single at x16 (PCIE2) / x8 (PCIE3) or dual at x8/x8 mode); 1 x PCI Express 2.0 x16 slot (PCIE4 @ x4 mode); 1 x PCI Express 2.0 x1 slot; 2 x PCI slots; Supports AMD Quad CrossFireX, 3-Way CrossFireX and CrossFire |
| Видео |
Supports Intel HD Graphics Built-in Visuals: Intel Quick Sync Video 2.0, Intel InTru 3D, Intel Clear Video HD Technology, Intel Insider, Intel HD Graphics 2500/4000 with Intel Ivy Bridge CPU; Multi VGA Output options: D-Sub, DVI-D and HDMI |
| Аудио |
7.1 CH HD Audio with Content Protection (Realtek ALC892 Audio Codec); Premium Blu-ray audio support; Supports THX TruStudio |
| LAN |
PCIE x1 Gigabit LAN 10/100/1000 Mb/s; Realtek RTL8111E; Supports Wake-On-LAN; Supports LAN Cable Detection; Supports Energy Efficient Ethernet 802.3az; Supports PXE |
| BIOS |
64Mb AMI UEFI Legal BIOS with GUI support; Supports "Plug and Play"; ACPI 1.1 Compliance Wake Up Events; Supports jumperfree; SMBIOS 2.3.1 Support; CPU Core, IGPU, DRAM, 1.8V PLL, VTT, VCCSA Voltage Multi-adjustment |
| Форм фактор |
ATX; 30.5 cm x 21.8 cm |
| Гаранционен срок |
36 месеца |
