Характеристики
Характеристики
| Чипсет | Intel B150 |
|---|---|
| Съвместими процесори | Intel Socket 1151 for 6th Generation Core i7/Core i5/Core i3/Pentium/Celeron Processors, Supports Intel 14 nm CPU, Supports Intel Turbo Boost Technology 2.0 |
| Памет | 4 x DIMM, Max. 64GB, DDR3 1866(O.C.)/1600/1333 MHz Non-ECC, Un-buffered Memory, Supports Intel Extreme Memory Profile (XMP) |
| Multi-GPU Support | Supports AMD CrossFireX Technology |
| Портове | 1 x PS/2 keyboard/mouse combo port(s), 1 x DVI-D, 1 x D-Sub, 1 x LAN (RJ45) port(s), 1 x USB 5Gb/s port(s) Type-C ( support 3A power output ), 2 x USB 3.0, 4 x USB 2.0, 3 x Audio jack(s) |
| Слотове | 1 x PCIe 3.0/2.0 x16 (x16 mode, gray), 1 x PCIe 3.0/2.0 x16 (max at x4 mode, black), 2 x PCIe 3.0/2.0 x1, 3 x PCI |
| Конектори | 1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s); 1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s); 1 x COM port(s) connector(s); 6 x SATA 6Gb/s connector(s); 1 x CPU Fan connector(s) (1 x 4 -pin, [White]); 2 x Chassis Fan connector(s) (2 x 4 -pin, [Black]); 1 x S/PDIF out header(s); 1 x 24-pin EATX Power connector(s); 1 x 8-pin ATX 12V Power connector(s); 1 x Front panel audio connector(s) (AAFP); 1 x System panel(s); 1 x Clear CMOS jumper(s); |
| Дисков интерфейс | Intel B150 chipset : 6 x SATA 6Gb/s port(s), gray |
| Видео | Integrated Graphics Processor, Intel HD Graphics support Multi-VGA output support: DVI-D/RGB ports, Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz, Supports RGB with max. resolution 1920 x 1200 @ 60 Hz, Maximum shared memory of 1024 MB |
| Аудио | Realtek ALC887 8-Channel High Definition Audio CODEC, Supports: Jack-detection, Front Panel Jack-retasking, LED-illuminated design - Brighten up your build with the gorgeous illuminated audio trace path, Audio Shielding: Ensures precision analog/digital s |
| LAN | Realtek 8111GR, 1 x Gigabit LAN Controller(s), ASUS LAN Guard |
| BIOS | 128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS3.0, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 3, ASUS CrashFree BIOS 3, Quick Note, Last Modified log, F12 PrintScreen, F3 Shortcut functions and ASUS DRAM SPD (Serial Presence Detect) memor |
| Форм фактор | ATX Form Factor 12 inch x 8.6 inch (30.5 cm x 21.8 cm) |
| Аксесоари | User's manual, I/O Shield, 2 x SATA 6Gb/s cable(s), 1 x Supporting DVD |
| Други | ASUS 5X Protection II, ASUS EPU, AI Suite 3, Ai Charger, Anti-Surge, Low EMI Solution, ESD Guards, USB 3.0 Boost, Mobo Connect, PC Cleaner, ASUS Quiet Thermal Solution, ASUS EZ DIY, ASUS Q-Design, Media Streamer |
| Гаранционен срок | 36 месеца |
