Характеристики
Характеристики
| Чипсет | Intel B150 |
|---|---|
| Съвместими процесори | Intel Socket 1151 for 6th Generation Core i7/Core i5/Core i3/Pentium/Celeron Processors, Supports Intel 14 nm CPU, Supports Intel Turbo Boost Technology 2.0 |
| Памет | 4 x DIMM, Max. 64GB, DDR3 1866(O.C.)/1600/1333 MHz Non-ECC, Un-buffered Memory, Supports Intel Extreme Memory Profile (XMP) |
| Портове | 1 x PS/2 keyboard (purple), 1 x PS/2 mouse (green), 1 x DVI-D, 1 x D-Sub, 1 x HDMI, 1 x LAN (RJ45) port(s), 4 x USB 3.0 (blue) Type-A, 2 x USB 2.0, 3 x Audio jack(s) |
| Слотове | 1 x PCIe 3.0/2.0 x16 (x16 mode, gray), 2 x PCIe 3.0/2.0 x1 |
| Конектори | 1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s); 2 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s); 1 x TPM header; 1 x LPT header; 1 x COM port(s) connector(s); 6 x SATA 6Gb/s connector(s); 1 x CPU Fan connector(s) (1 x 4 -pin); 2 x Chassis Fan connector(s) (2 x 4 -pin); 1 x S/PDIF out header(s); 1 x 24-pin EATX Power connector(s); 1 x 4-pin ATX 12V Power connector(s); 1 x Front panel audio connector(s) (AAFP); 1 x Internal speaker connector(s); 1 x System panel(s); 1 x Chassis Intrusion connector(s); 1 x Clear CMOS jumper(s); |
| Дисков интерфейс | Intel B150 chipset: 6 x SATA 6Gb/s port(s), gray |
| Видео | Integrated Graphics Processor Intel HD Graphics support; Multi-VGA output support: HDMI/DVI-D/RGB ports, Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz, Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz, Supports RGB wi |
| Аудио | Realtek® ALC887 8-Channel High Definition Audio CODEC, Supports: Jack-detection, Front Panel Jack-retasking, LED-illuminated design, Brighten up your build with the gorgeous illuminated audio trace path., Audio Shielding: Ensures precision analog/digital |
| LAN | Realtek RTL8111H, 1 x Gigabit LAN Controller(s), ASUS LAN Guard |
| BIOS | 128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS3.0, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3, Quick Note, Last Modified log, F12 PrintScreen, F3 Shortcut functions and ASUS DRAM SPD (Serial Presence Detect) memor |
| Форм фактор | mATX Form Factor 9.2 inch x 7.9 inch (23.4 cm x 20.1 cm) |
| Аксесоари | User's manua,l I/O Shield, 2 x SATA 6Gb/s cable(s), 1 x Supporting DVD |
| Други | ASUS 5X Protection II, ASUS EPU, AI Suite 3, Ai Charger, Anti-Surge, ESD Guards, USB 3.0 Boost, Mobo Connect, PC Cleaner, ASUS Quiet Thermal Solution, ASUS EZ DIY, ASUS Q-Design |
| Гаранционен срок | 36 месеца |
