Характеристики
Характеристики
| Чипсет | Intel C232 |
|---|---|
| Съвместими процесори | Intel Socket 1151 for Xeon E3-1200 v5 and 6th genereation CoreTM, Pentium and Celeron Processors, Supports Intel 14 nm CPU, Supports Intel Turbo Boost Technology 2.0 |
| Памет | 4 x DIMM, Max. 64GB, DDR4 2133 MHz ECC, Non-ECC, Un-buffered Memory, Dual Channel Memory Architecture, Supports Intel Extreme Memory Profile (XMP) |
| Multi-GPU Support | Supports AMD Quad-GPU CrossFireX Technology, Supports AMD 2-Way CrossFireX Technology |
| Портове | 1 x PS/2 keyboard (purple), 1 x PS/2 mouse (green), 1 x LAN (RJ45) port(s), 1 x USB 3.1 (red)Type-A, 1 x USB 3.1 Type-C, 4 x USB 3.0, 2 x USB 2.0, 1 x Optical S/PDIF out, 5 x Audio jack(s) |
| Слотове | 1 x PCIe 3.0/2.0 x16 (x16 mode, ), 1 x PCIe 3.0/2.0 x16 (max at x4 mode), 2 x PCIe 3.0/2.0 x1, 2 x PCI |
| Конектори | 1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s) (19-pin); 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s); 1 x M.2 Socket 3 with M Key design, type 2242/2260/2280/22110 storage devices support (Supports both SATA & PCIE SSD); 1 x COM port(s) connector(s); 6 x SATA 6Gb/s connector(s); 1 x CPU Fan connector(s) (1 x 4 -pin); 3 x Chassis Fan connector(s) (3 x 4 -pin); 1 x 24-pin EATX Power connector(s); 1 x 8-pin ATX 12V Power connector(s); 1 x Front panel audio connector(s) (AAFP); 1 x System panel(s); 1 x Thermal sensor connector(s); 1 x CPU OV; 1 x Clear CMOS jumper(s); 1 x Water Pump header (4-pin); 1 x ROG extension (ROG_EXT) header(s) |
| Дисков интерфейс | Intel® C232 chipset : 1 x M.2 Socket 3, with M Key design, type 2242/2260/2280/22110 storage devices support (Supports both SATA & PCIE SSD), 6 x SATA 6Gb/s port(s), Support Raid 0, 1, 5, 10, Intel Rapid Storage Technology Enterprise supports |
| Аудио | SupremeFX 8-Channel High Definition Audio CODEC, Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking, High quality 115 dB SNR stereo playback output |
| LAN | Intel I219LM, 1 x Gigabit LAN Controller(s), GameFirst technology, Anti-surge LANGuard |
| BIOS | 128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 3.0, WfM 2.0, SM BIOS 3.0, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F6 Qfan Control, F3 My Favorites, F9 Quick Note, Last Modified Log, F12 PrintScreen function, and ASUS DRAM SPD (Serial |
| Форм фактор | ATX Form Factor 12 inch x 9.6 inch (30.5 cm x 24.4 cm) |
| Аксесоари | User's manual I/O Shield, 4 x SATA 6Gb/s cable(s), 1 x M.2 Screw Package, 1 x pack of cable tie, 1 x Supporting DVD, 1 x 12 in 1 Cable Label (s) |
| Гаранционен срок | 36 месеца |
