| Чипсет |
AMD A55 FCH (Hudson D2) |
| Съвместими процесори |
AMD Socket FM2 A- series/AthlonSeries Processors; AMD Turbo Core Technology 3.0 Supports; Supports CPU up to 4 cores |
| Памет |
2 x DDR3 DIMM, max. 32GB, DDR3 1866/1600/1333/1066 MHz, non-ECC un-buffered memory Dual Channel memory architecture; Support AMD Memory Profile(AMP) memory |
| Портове |
1 x PS/2 Keyboard; 1 x PS/2 Mouse; 1 x DVI Port; 1 x D-Sub Output port; 1 x LAN (RJ45) port; 4 x USB 2.0/1.1 ports; 8 channel Audio 3 Jacks |
| Слотове |
1x PCI Express 2.0 x16 slot; 1 x PCI Express 2.0 x1 slot; 1 x PCI slot |
| Дисков интерфейс |
AMD A55 FCH: 4 x Serial ATA 3Gb/s connectors(blue) with RAID 0, RAID 1,RAID 10 and JBOD support |
| Видео |
Integrated AMD Radeon HD 7000 Series Graphics in the A-Series APU; Support DVI-D & D-Sub; Supports DVI with max. resolution 2560 X 1600@60 HZ; Supports D-Sub with max. resolution 1920 X 1600@60 HZ; AMD Dual Graphics technology support |
| Аудио |
Realtek ALC 887-VD 8-Channel High Definition Audio CODEC |
| LAN |
RTL8111F Gigabit LAN controller |
| BIOS |
32 Mb Flash ROM, UEFI BIOS, PnP, DMI v2.0, WfM2.0, SM BIOS V2.6, ACPI V2.0a |
| Форм фактор |
micro ATX |
| Други |
Special 100% ALL High-quality Conductive Polymer Capacitors; Dimensions 22.6cm x 17.8cm |
| Гаранционен срок |
36 месеца |
