| Чипсет |
AMD A85X FCH(Hudson D4) |
| Съвместими процесори |
AMD Socket FM2 Athlon/A- Series Processors ; Supports CPU up to 4 cores ; Supports AMD Turbo Core 3.0 Technology |
| Памет |
4 x DIMM, Max. 64GB, DDR3 2400(O.C.)/2250(O.C.)/2200(O.C.)/2133(O.C.)/2000(O.C.)/1866/1600/1333/1066 MHz Non-ECC, Un-buffered Memory; Dual Channel Memory Architecture; Support AMD Memory Profile (AMP) memory |
| Портове |
1 x PS/2 keyboard/mouse combo port(s); 1 x DVI; 1 x D-Sub; 1 x HDMI; 1 x eSATA; 1 x LAN (RJ45) port(s); 2 x USB 3.0; 4 x USB 2.0; 1 x Optical S/PDIF out; 6 x Audio jack(s) |
| Слотове |
2 x PCIe 2.0 x16 (x16/x4); 1 x PCIe 2.0 x1; 1 x PCI |
| Дисков интерфейс |
AMD A85X FCH(Hudson D4) chipset : 7 x SATA 6Gb/s port(s), gray; 1 x eSATA 6Gb/s port(s), red ; Support Raid 0, 1, 5, 10, JBOD |
| Видео |
Integrated AMD Radeon HD 7000 Series Graphics in A-series APU; Multi-VGA output support : HDMI/DVI/RGB ports; - Supports HDMI with max. resolution 1920 x 1080 @ 60 Hz; - Supports DVI with max. resolution 2560 x 1600 @ 60 Hz; - Supports RGB with max. resol |
| Аудио |
Realtek ALC887 8-Channel High Definition Audio CODEC |
| LAN |
Realtek 8111F, 1 x Gigabit LAN Controller(s) |
| BIOS |
64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.7, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3, F12 PrintScreen Function, F3 Shortcut Function and ASUS DRAM SPD (Serial Presence Detect) memory information |
| Форм фактор |
microATX |
| Други |
Dimensions 24.4 cm x 24.4 cm |
| Гаранционен срок |
36 месеца |
