Характеристики
Характеристики
| Чипсет | Intel H170 |
|---|---|
| Съвместими процесори | Intel for 6th Generation Core i7/Core i5/Core i3/Pentium/Celeron Processors, Supports Intel 14 nm CPU, Supports Intel Turbo Boost Technology 2.0 |
| Памет | 4 x DIMM, Max. 64GB, DDR3 1866(O.C.)/1600/1333 MHz Non-ECC, Un-buffered Memory, Supports Intel Extreme Memory Profile (XMP) |
| Multi-GPU Support | Supports AMD 2-Way CrossFireX Technology |
| Портове | 1 x PS/2 keyboard (purple), 1 x PS/2 mouse (green), 1 x DVI-D, 1 x D-Sub, 1 x HDMI, 1 x LAN (RJ45) port(s), 4 x USB 3.0 (blue), 2 x USB 2.0, 3 x Audio jack(s) |
| Слотове | 1 x PCIe 3.0/2.0 x1 (x16 mode, gray), 1 x PCIe 3.0/2.0 x1 (max at x4 mode, black), 1 x PCIe 3.0/2.0 x1, 1 x PCI |
| Конектори | 2 x USB 3.0 connector(s) support(s) additional 4 USB 3.0 port(s) (19-pin, blue); 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s); 1 x M.2 Socket 3 for M Key, type 2242/2260/2280 devices; 1 x LPT header; 1 x COM port(s) connector(s); 4 x SATA 6Gb/s connector(s); 1 x CPU Fan connector(s) (1 x 4 -pin); 2 x Chassis Fan connector(s) (2 x 4 -pin); 1 x S/PDIF out header(s); 1 x 24-pin EATX Power connector(s); 1 x 8-pin ATX 12V Power connector(s); 1 x Front panel audio connector(s) (AAFP); 1 x System panel(s); 1 x Clear CMOS jumper(s); 1 x 14-1 pin TPM connector; |
| Дисков интерфейс | Intel H170 chipset: 4 x SATA 6Gb/s port(s), gray, 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (both SATA & PCIE mode), Support Raid 0, 1, 5, 10, Supports Intel Smart Response Technology |
| Видео | Integrated Graphics Processor- Intel® HD Graphics support, Multi-VGA output support: HDMI/DVI-D/RGB ports, Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz, Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz, Supports RGB |
| Аудио | Realtek ALC887-VD2 8-Channel High Definition Audio CODEC, Supports: Jack-detection, Front Panel Jack-retasking, Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference, Dedicated audio PCB layers: Separa |
| LAN | Realtek RTL8111H, 1 x Gigabit LAN Controller(s) |
| BIOS | 128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0 ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Quick Note, Last Modified log, F12 PrintScreen, and ASUS DRAM SPD ( |
| Форм фактор | uATX Form Factor 9.6 inch x 8.8 inch (24.4 cm x 22.4 cm) |
| Аксесоари | User's manual, I/O Shield, 2 x SATA 6Gb/s cable(s), 1 x M.2 Screw Package, 1 x Supporting DVD |
| Други | ASUS EPU, GPU Boost, AI Suite 3, Ai Charger, Anti-Surge, Low EMI Solution, USB 3.0 Boost, Mobo Connect, PC Cleaner |
| Гаранционен срок | 36 месеца |
