| Чипсет |
Intel H87 |
| Процесор |
Intel Socket 1150 for 4th Generation Core i7/Core i5/Core i3/Pentium/Celeron Processors |
| Съвместими процесори |
Supports Intel 22 nm CPU; Supports Intel Turbo Boost Technology 2.0 |
| Памет |
4 x DIMM, Max. 32GB, DDR3 1600/1333/1066 MHz Non-ECC, Un-buffered Memory; Dual Channel Memory Architecture; Supports Intel Extreme Memory Profile (XMP) |
| Портове |
1 x PS/2 keyboard/mouse combo port(s); 1 x DVI; 1 x D-Sub; 1 x DisplayPort; 1 x HDMI; 1 x LAN (RJ45) port(s); 4 x USB 3.0 (blue); 2 x USB 2.0; 1 x Optical S/PDIF out; 3 x Audio jack(s) |
| Слотове |
1 x PCIe 3.0/2.0 x16 (x16 mode, yellow); 1 x PCIe 2.0 x16 (x4 mode, dark brown); 2 x PCIe 2.0 x1; 3 x PCI |
| Дисков интерфейс |
Intel H87 chipset :6 x SATA 6Gb/s port(s), yellow; Support Raid 0, 1, 5, 10; Supports Intel Smart Response Technology, Intel Rapid Start Technology, Intel Smart Connect Technology |
| Видео |
Multi-VGA output support : HDMI/DVI/RGB/DisplayPort port; - Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz; - Supports DVI with max. resolution 1920 x 1200 @ 60 Hz; - Supports RGB with max. resolution 1920 x 1200 @ 60 Hz |
| Аудио |
Realtek ALC887 8-Channel High Definition Audio CODEC - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking; Audio Feature :- Optical S/PDIF out port(s) at back panel |
| LAN |
Realtek 8111G, 1 x Gigabit LAN Controller(s) |
| BIOS |
64 Mb Flash ROM, UEFI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.7, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3, F12 PrintScreen Function, F3 Shortcut Function and ASUS DRAM SPD (Serial Presence Detect) memory information |
| Форм фактор |
ATX |
| Други |
Dimensions 30.5 cm x 21.8 cm |
| Гаранционен срок |
36 месеца |
