| Чипсет |
Intel H87 |
| Процесор |
Intel Socket 1150 for 4th Generation Core i7/Core i5/Core i3/Pentium/Celeron Processors |
| Съвместими процесори |
Supports Intel 22 nm CPU; Supports Intel Turbo Boost Technology 2.0 |
| Памет |
2 x U-DIMM, Max. 16GB, DDR3 1600/1333/1066 MHz Non-ECC, Un-buffered Memory; Dual Channel Memory Architecture |
| Портове |
1 x PS/2 keyboard (purple); 1 x DVI-D; 1 x D-Sub; 1 x HDMI; 1 x LAN (RJ45) port(s); 4 x USB 3.0; 4 x USB 2.0; 1 x Optical S/PDIF out; 3 x Audio jack(s) |
| Слотове |
1 x PCIe 3.0/2.0 x16 |
| Дисков интерфейс |
Intel H87 chipset :6 x SATA 6Gb/s port(s), yellow; Support Raid 0, 1, 5, 10 |
| Видео |
Integrated Graphics Processor- Supports HDMI with max. resolution 4096 x 2304 @ 24 Hz; - Supports DVI with max. resolution 1920 x 1200 @ 60 Hz; - Supports RGB with max. resolution 1920 x 1200 @ 60 Hz; Maximum shared memory of 1024 MB |
| Аудио |
Realtek ALC887 8-Channel High Definition Audio CODEC |
| LAN |
Intel I217, 1 x Gigabit LAN Controller(s) |
| BIOS |
64 Mb Flash ROM, AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.5, ACPI 2.0a |
| Форм фактор |
Mini ITX |
| Други |
Dimensions 17 cm x 17 cm |
| Гаранционен срок |
36 месеца |
