| Чипсет |
Intel H87 |
| Процесор |
Intel Socket 1150 for 4th Generation Core i7/Core i5/Core i3/Pentium/Celeron Processors, Supports Intel 22 nm CPU, Supports Intel Turbo Boost Technology 2.0, * The Intel Turbo Boost Technology 2.0 support depends on the CPU types. |
| Памет |
4 x DIMM, Max. 32GB, DDR3 1600/1333/1066 MHz Non-ECC, Un-buffered Memory, Dual Channel Memory Architecture, Supports Intel Extreme Memory Profile (XMP), * Hyper DIMM support is subject to the physical characteristics of individual CPUs. |
| Портове |
PS/2 keyboard (purple), PS/2 mouse (green), DVI-D, D-Sub, HDMI, LAN (RJ45) port(s), 4 x USB 3.0, 2 x USB 2.0, 3 x Audio jack(s) |
| Слотове |
PCIe 3.0/2.0 x16 (x16 mode, yellow), 3 x PCIe 2.0 x1 |
| Дисков интерфейс |
Intel H87 chipset : 6 x SATA 6Gb/s port(s), yellow, Support Raid 0, 1, 5, 10, Supports Intel Smart Response Technology, Intel Rapid Start Technology, Intel Smart Connect Technology |
| Видео |
Integrated Graphics Processor, Multi-VGA output support : HDMI/DVI-D/RGB ports, - Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz, - Supports DVI with max. resolution 1920 x 1200 @ 60 Hz |
| Аудио |
Realtek ALC887 8-Channel High Definition Audio CODEC, Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking |
| LAN |
Realtek 8111G, 1 x Gigabit LAN Controller(s) |
| BIOS |
64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.5, ACPI 2.0a, Multi-language BIOS,ASUS EZ Flash 2, ASUS CrashFree BIOS 3, My Favorites, Quick Note, Last Modified log, F12 PrintScreen, F3 Shortcut functions |
| Форм фактор |
uATX |
| Други |
Dimensions 24.4 cm x 19.3 cm |
| Гаранционен срок |
36 месеца |
