Характеристики
Характеристики
| Чипсет | Intel H97 |
|---|---|
| Процесор | Intel Socket 1150 for the 5th/New 4th/4th Generation Core i7/Core i5/Core i3/Pentium/Celeron Processors , Supports Intel 22 nm CPU, Supports Intel Turbo Boost Technology 2.0 |
| Памет | 4 x DIMM, Max. 32GB, DDR3 1600/1333 MHz Non-ECC, Un-buffered Memory *, Dual Channel Memory Architecture , Supports Intel Extreme Memory Profile (XMP) |
| Multi-GPU Support | Supports AMD Quad-GPU CrossFireX Technology |
| Портове | PS/2 keyboard/mouse combo port(s), DVI-D, D-Sub, HDMI, LAN (RJ45) port(s), 4 x USB 3.0 (blue), 2 x USB 2.0 , 6 x Audio jack(s) |
| Слотове | 1 x PCIe 3.0/2.0 x16 (x16 mode, gray) , 1 x PCIe 2.0 x16 (max at x4 mode, black) *1, 2 x PCIe x1 , 3 x PCI |
| Конектори | 1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s) (19-pin), 3 x USB 2.0 connector(s) support(s) additional 6 USB 2.0 port(s), 1 x SATA Express connector: black, compatible with 2 x SATA 6.0 Gb/s ports, 1 x M.2 Socket 3 for M Key, type 2260/2280 devices, 1 x TPM header, 1 x COM port(s) connector(s), 4 x SATA 6Gb/s connector(s), 1 x CPU Fan connector(s) (1 x 4 -pin), 1 x CPU OPT Fan connector(s) (1 x 4 -pin), 3 x Chassis Fan connector(s) (3 x 4 -pin), 1 x S/PDIF out header(s), 1 x 24-pin EATX Power connector(s), 1 x 8-pin ATX 12V Power connector(s), 1 x Front panel audio connector(s) (AAFP), 1 x System panel(s) , 1 x Thermal sensor connector(s), 1 x Clear CMOS jumper(s) |
| Дисков интерфейс | 1 x SATA Express port, , compatible with 2 x SATA 6.0 Gb/s ports, 1 x M.2 Socket 3, , with M Key, type 2260/2280 storage devices support (both SATA & PCIE mode)*2, 4 x SATA 6Gb/s port(s), gray, Support Raid 0, 1, 5, 10 |
| Видео | Integrated Graphics Processor- Intel HD Graphics support , Multi-VGA output support : HDMI/DVI-D/RGB ports , Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz, Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz |
| Аудио | SupremeFX 8-Channel High Definition Audio CODEC featuring Crystal Sound 2, Supports : Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking, High quality 115 dB SNR stereo playback output, High-fidelity audio OP AMP(s) |
| LAN | Intel I218V, 1 x Gigabit LAN Controller(s), featuring GAMEFIRST II Gigabit Intel LAN Connection- 802.3az Energy Efficient Ethernet (EEE) appliance |
| BIOS | 64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI 2.7, WfM 2.0, SM BIOS 2.8, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 2, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Quick Note, Last Modified Log, F12 PrintScreen function |
| Форм фактор | ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) |
| Аксесоари | User's manual, ASUS Q-Shield, 4 x SATA 6Gb/s cable(s) |
| Гаранционен срок | 36 месеца |
