| Чипсет |
Intel Z77 |
| Съвместими процесори |
Intel Socket 1155 for 3rd/2nd Generation Core i7/Core i5/Core i3/Pentium/Celeron; Supports Intel 22 nm CPU; Supports Intel 32 nm CPU; Supports Intel Turbo Boost Technology 2.0 |
| Памет |
4 x DIMM, Max. 32GB, DDR3 2800(O.C.)/2666(O.C.)/2600(O.C.)/2400(O.C.)/2200(O.C.)/2133(O.C.)/1866(O.C.)/1600/1333/1066 MHz Non-ECC, Un-buffered Memory; Dual Channel Memory Architecture; Supports Intel Extreme Memory Profile (XMP) |
| Портове |
1 x DisplayPort; 1 x HDMI; 1 x eSATA 3Gb/s; 1 x LAN (RJ45) port(s); 4 x USB 3.0; 4 x USB 2.0; 1 x Optical S/PDIF out; 1 x Optical S/PDIF in; 5 x Audio jack(s); 1 x Clear CMOS button(s); 1 x ROG Connect On/ Off switch(es) |
| Слотове |
3 x PCIe 3.0/2.0 x16 (x16 or dual x8 or x8/x4/x4); 1 x PCIe 2.0 x4; 3 x PCIe 2.0 x1; 1 x mini-PCIe 2.0 x1 Supports: NVIDIA SLI; AMD 3-Way CrossFireX; AMD CrossFireX; LucidLogix Virtu MVP |
| Дисков интерфейс |
Intel Z77 chipset: 2 x SATA 6Gb/s port(s), red; 2 x SATA 3Gb/s port(s), black; 1 x eSATA 3Gb/s port(s), red; 1 x mini-SATA 3Gb/s port(s) , black; Support Raid 0, 1, 5, 10; Supports Intel Smart Response Technology, Intel Rapid Start Technology |
| Видео |
Multi-VGA output support : HDMI/DisplayPort ports; Supports Intel HD Graphics, InTru 3D, Quick Sync Video, Clear Video HD Technology, Insider |
| Аудио |
SupremeFX IV built-in 7.1-Channel High Definition Audio CODEC; Output Signal-to-Noise Ratio (A-Weighted): 110 dB; Output THD+N at 1kHz: 95 dB; TI 6120A2 high fidelity headphone amplifier; Supports: Jack-detection, Multi-streaming |
| LAN |
Intel, 1 x Gigabit LAN Controller(s) |
| BIOS |
64Mb UEFI AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.5, ACPI2.0a Multi-Language BIOS |
| Форм фактор |
Extended ATX |
| Други |
Dimensions 30.5 cm x 25.7 cm |
| Гаранционен срок |
36 месеца |
