| Чипсет |
Intel Z87 |
| Процесор |
Intel Socket 1150 for 4th Generation Core i7/Core i5/Core i3/Pentium/Celeron Processors , Supports Intel 22 nm CPU, Supports Intel Turbo Boost Technology 2.0 |
| Памет |
4 x DIMM, Max. 32GB, DDR3 3100(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666(O.C.)/2600(O.C.)/2500(O.C.)/2400(O.C.)/2200(O.C.)/2133(O.C.)/2000(O.C.)/1866(O.C.)/1800(O.C.)/1600/1333 MHz Non-ECC, Un-buffered Memory , Dual Channel Memory Architecture |
| Multi-GPU Support |
Supports NVIDIA 4-Way SLI Technology, Supports AMD CrossFireX Technology |
| Портове |
Intel Z87 chipset : *6 ,4 x USB 3.0 port(s) (2 at back panel, blue, 2 at mid-board) Intel Z87 chipset : *7 ,8 x USB 2.0 port(s) (2 at back panel, black, 6 at mid-board) ASMedia USB 3.0 controller : 4 x USB 3.0 port(s) (4 at back panel, blue) |
| Слотове |
5 x PCIe 3.0/2.0 x16 (x16 or dual x8 or x8/x16/x8 or x8/x16/x8/x8) *1, PCIe 2.0 x4, mini-PCIe 2.0 x1 *2 |
| Дисков интерфейс |
Intel Z87 chipset : *3 6 x SATA 6Gb/s port(s), red, Support Raid 0, 1, 5, 10, Supports Intel Smart Response Technology, Intel Rapid Start Technology, Intel® Smart Connect Technology *4, Intel® Z87 chipset : , 1 x M.2 (NGFF) Socket 2 on mPCIe Combo II exp |
| Видео |
Integrated Graphics Processor , Multi-VGA output support : HDMI/DisplayPort ports , - Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz, - Supports DisplayPort with max. resolution 4096 x 2160 @ 24 Hz / 3840 x 2160 @ 60 Hz *9 |
| Аудио |
Realtek ALC1150 8-Channel High Definition Audio CODEC, Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking Audio Feature : Blu-ray audio layer Content Protection ,Optical S/PDIF out port(s) at back panel |
| LAN |
Intel I217V, 1 x Gigabit LAN Controller(s) |
| BIOS |
64Mb UEFI AMI BIOS, PnP, DMI2.7, WfM2.0, SM BIOS 2.7, ACPI5.0a Multi-Language BIOS |
| Форм фактор |
ATX |
| Аксесоари |
User's manual, I/O Shield, 10 x SATA 6Gb/s cable(s), ASUS 2T2R dual band Wi-Fi moving antennas (Wi-Fi 802.11a/b/g/n/ac compliant), 3-Way SLI bridge(s), 4-Way SLI bridge(s), SLI bridge(s), CrossFire cable(s), Q-connector(s) (2 in 1) , ROG Connect cable(s) |
| Други |
Dimensions 30.5 cm x 24.4 cm |
| Гаранционен срок |
36 месеца |
