| Чипсет |
Intel Z87 |
| Съвместими процесори |
Intel Socket 1150 for 4th Generation Core i7/Core i5/Core i3/Pentium/Celeron Processors |
| Памет |
4 x DIMM, Max. 32GB, DDR3 3100(O.C)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666(O.C.)/2600(O.C.)/2500(O.C.)/2400(O.C.)/2200(O.C.)/2133(O.C.)/2000(O.C.)/1866(O.C.)/1800(O.C.)/1600/1333 MHz Non-ECC, Un-buffered Memory |
| Портове |
1 x DisplayPort; 1 x HDMI; 1 x LAN (RJ45) port(s); 6 x USB 3.0 (blue); 4 x USB 2.0; 1 x Optical S/PDIF out; 6 x Audio jack(s); 1 x Clear CMOS button(s); 1 x ROG Connect On/ Off switch(es) |
| Слотове |
3 x PCIe 3.0/2.0 x16 (x16 or dual x8 or x8/x4/x4); 1 x mini-PCIe 2.0 x1; 3 x PCIe 2.0 x1 |
| Дисков интерфейс |
Intel Z87 chipset: 6 x SATA 6Gb/s port(s), red; Support Raid 0, 1, 5, 10; Supports Intel Smart Response Technology, Intel Rapid Start Technology, Intel Smart Connect Technology; Intel Z87 chipset: 1 x M.2 (NGFF) Socket 2 on mPCIe Combo II expansion card(s |
| Видео |
Integrated Graphics Processor; Multi-VGA output support : HDMI/DisplayPort ports; Supports Intel InTru 3D, Quick Sync Video, Clear Video HD Technology, Insider |
| Аудио |
ROG SupremeFX Formula 8-Channel High Definition Audio CODEC; Supports: Jack-detection, Multi-streaming; SupremeFX Shielding Technology; Cirrus Logic CS4398 DAC: 120 dB SNR, 107 dB THD+N (Max. 192 kHz/ 24 -bit); TI 6120A2 high fidelity headphone amplifier; |
| LAN |
Intel I217V, 1 x Gigabit LAN Controller(s) |
| BIOS |
64Mb UEFI AMI BIOS, PnP, DMI2.7, WfM2.0, SM BIOS 2.7, ACPI5.0a Multi-Language BIOS |
| Форм фактор |
ATX |
| Гаранционен срок |
36 месеца |
