| Чипсет |
Intel Z87 |
| Процесор |
Intel Socket 1150 for 4th Generation Core i7/Core i5/Core i3/Pentium/Celeron Processors |
| Съвместими процесори |
Supports Intel 22 nm CPU; Supports Intel Turbo Boost Technology 2.0 |
| Памет |
4 x DIMM, Max. 32GB, DDR3 ; 3000(O.C.)/2933(O.C.)/2800(O.C.)/2666(O.C.)/2600(O.C.)/2500(O.C.)/2400(O.C.)/2200(O.C.)/2133(O.C.)/2000(O.C.)/1866(O.C.)/1800(O.C.)/1600/1333 MHz ; Non-ECC, Un-buffered Memory; Dual Channel Memory Architecture |
| Портове |
1 x PS/2 keyboard/mouse combo port(s); 1 x HDMI; 1 x LAN (RJ45) port(s); 4 x USB 3.0; 4 x USB 2.0; 1 x Optical S/PDIF out; 6 x Audio jack(s); 1 x USB BIOS Flashback Button(s) |
| Слотове |
2 x PCIe 3.0/2.0 x16 (x16 or dual x8, red); 1 x PCIe 2.0 x16 (black) ; 3 x PCIe 2.0 x1; Supports NVIDIA Quad-GPU SLI Technology; Supports AMD Quad-GPU CrossFireX Technology |
| Дисков интерфейс |
Intel Z87 chipset :6 x SATA 6Gb/s port(s), red; Support Raid 0, 1, 5, 10; Supports Intel Smart Response Technology, Intel Rapid Start Technology, Intel Smart Connect Technology *3; ASMedia ASM1061 controller : 2 x SATA 6Gb/s port(s) |
| Видео |
Integrated Graphics Processor- Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz; Supports Intel InTru 3D, Quick Sync Video, Clear Video HD Technology |
| Аудио |
ROG SupremeFX 8-Channel High Definition Audio CODEC- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking; Audio Feature :- SupremeFX Shielding Technology; - ELNA premium audio capacitors; - Blu-ray audio layer Content Protection |
| LAN |
Intel I217V, 1 x Gigabit LAN Controller(s) |
| BIOS |
64Mb UEFI AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.5, ACPI2.0a Multi-Language BIOS |
| Форм фактор |
ATX |
| Други |
Dimensions 30.5 cm x 24.4 cm |
| Гаранционен срок |
36 месеца |
