| Чипсет |
Intel B75 |
| Съвместими процесори |
Intel Socket 1155 for 3rd/2nd Generation Processors; Supports Intel 22 nm CPU; Supports Intel 32 nm CPU; Supports Intel Turbo Boost Technology 2.0 |
| Памет |
4 x DIMM, Max. 32GB, DDR3 2200(O.C.)/2133(O.C.)/2000(O.C.)/1866(O.C.)/1600/1333/1066 MHz Non-ECC, Un-buffered Memory; Dual Channel Memory Architecture; Supports Intel Extreme Memory Profile (XMP) |
| Портове |
1 x PS/2 keyboard (purple); 1 x PS/2 mouse (green); 1 x DVI; 1 x D-Sub; 1 x LAN (RJ45) port(s); 2 x USB 3.0; 4 x USB 2.0; 3 x Audio jack(s) |
| Слотове |
1 x PCIe 3.0/2.0 x16 (blue); 1 x PCIe 2.0 x16 (x4 mode, black); 2 x PCIe 2.0 x1; 3 x PCI; Supports AMD Quad-GPU CrossFireX Technology; Supports LucidLogix Virtu MVP Technology |
| Дисков интерфейс |
Intel B75 chipset: 1 x SATA 6Gb/s port(s), gray; 5 x SATA 3Gb/s port(s), blue; Supports Intel Rapid Start Technology, Intel Smart Connect Technology |
| Видео |
Multi-VGA output support : DVI/RGB ports; Supports DVI with max. resolution 1920 x 1200 @ 60 Hz; Supports RGB with max. resolution 2048 x 1536 @ 75 Hz; Maximum shared memory of 1696 MB; Supports Intel HD Graphics |
| Аудио |
Realtek ALC887-VD2 8-Channel High Definition Audio CODEC; Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking; Audio Feature: Optical S/PDIF out port(s) at back panel |
| LAN |
Realtek 8111E , 1 x Gigabit LAN Controller(s) |
| BIOS |
64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.6, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3, F12 PrintScreen Function, F3 Shortcut Function and ASUS DRAM SPD (Serial Presence Detect) memory information |
| Форм фактор |
ATX |
| Други |
Dimensions 30.5 cm x 21.9 cm |
| Гаранционен срок |
36 месеца |
