| Чипсет |
Intel H61 |
| Процесор |
Intel Socket 1155 for 3rd/2nd Generation Core i7/Core i5/Core i3/Pentium/Celeron Processors |
| Съвместими процесори |
Supports Intel 22 nm CPU; Supports Intel Turbo Boost Technology 2.0 |
| Памет |
2 x DIMM, Max. 16GB, DDR3 2200 (O.C.) / 2133(O.C.) / 2000 (O.C.) / 1866 (O.C.) / 1600 / 1333 / 1066 MHz Non-ECC, Un-buffered Memory; DDR3 1600MHz and higher memory frequency is supported by Intel® 3rd generation processors |
| Портове |
1 x PS/2 keyboard (purple); 1 x PS/2 mouse (green); 1 x D-Sub; 1 x LAN (RJ45) port(s); 4 x USB 2.0; 3 x Audio jack(s) |
| Слотове |
1 x PCIe 3.0/2.0 x16; 2 x PCIe 2.0 x1 |
| Дисков интерфейс |
Intel H61 chipset : 4 x SATA 3Gb/s port(s) |
| Видео |
Supports D-Sub with max. resolution 2048 x 1536 @ 75 Hz; Maximum shared memory of 1748 MB |
| Аудио |
VIA VT1708S 8-Channel High Definition Audio CODEC - Supports : Multi-streaming |
| LAN |
Realtek 8111F, 1 x Gigabit LAN Controller(s) |
| BIOS |
64Mb Flash ROM, UEFI BIOS, PnP, DMI v2.0, WfM2.0, SMBIOS v2.7, ACPI v2.0a , Multi-language BIOS |
| Форм фактор |
micro ATX |
| Други |
Dimensions 22.6 cm x 17.3 cm |
| Гаранционен срок |
36 месеца |
