| Чипсет |
Intel H61 Express Chipset |
| Процесор |
Intel Socket 1155 for 3rd/2nd Generation Core i7/Core i5/Core i3/Pentium/Celeron Processors |
| Съвместими процесори |
Supports Intel 22/32 nm CPU; Supports Intel Turbo Boost Technology 2.0 |
| Памет |
4 x DIMM, Max. 32GB, DDR3 2200 (O.C.) / 2000 (O.C.) / 1800 (O.C.) / 1600 (O.C.)/ 1333 / 1066 MHz Non-ECC, Un-buffered Memory; DDR3 1600MHz and higher memory frequency is supported by Intel 3rd generation processors; Dual Channel Memory Architecture |
| Портове |
1 x PS/2 keyboard/mouse combo port(s); 1 x LAN (RJ45) port(s); 1 x D-Sub; 1 x DVI; 6 x USB 2.0; 3 x Audio jack(s) |
| Слотове |
1 x PCIe 3.02/2.0 x16; 1 x PCIe 2.0 x1; 2 x PCI |
| Дисков интерфейс |
Intel H61 chipset :4 x SATA 3Gb/s port(s), blue; Supports Intel Smart Response Technology |
| Видео |
Multi-VGA output support : DVI/RGB ports; - Supports DVI with max. resolution 1920 x 1200 @ 60 Hz; - Supports RGB with max. resolution 2048 x 1536 @ 75 Hz |
| Аудио |
VIA VT1708S 8-Channel High Definition Audio CODEC |
| LAN |
Realtek 8111F , 1 x Gigabit LAN Controller(s) |
| BIOS |
64Mb Flash ROM, UEFI BIOS, PnP, DMI v2.0, WfM2.0, SMBIOS v2.5, ACPI v2.0a |
| Форм фактор |
micro ATX |
| Други |
Dimensions 24.4 cm x 22.4 cm |
| Гаранционен срок |
36 месеца |
