| Чипсет |
Intel Z77 |
| Съвместими процесори |
Intel Socket 1155 for 3rd/2nd Generation Processors; Supports Intel 22 nm CPU; Supports Intel 32 nm CPU; Supports Intel Turbo Boost Technology 2.0 types. |
| Памет |
4 x DIMM, Max. 32GB, DDR3 MHz Memory; Dual Channel Memory Architecture; Supports Intel Extreme Memory Profile (XMP) |
| Портове |
1 x PS/2 keyboard/mouse combo port(s); 1 x DVI; 1 x D-Sub; 1 x HDMI; 1 x LAN (RJ45) port(s); 2 x USB 3.0; 4 x USB 2.0; 1 x Optical S/PDIF out; 3 x Audio jack(s) |
| Слотове |
1 x PCIe 3.0/2.0 x16 (blue); 1 x PCIe 2.0 x16 (x4 mode, black); 2 x PCIe 2.0 x1; 3 x PCI; Supports AMD Quad-GPU CrossFireX Technology; Supports LucidLogix® Virtu MVP Technology |
| Дисков интерфейс |
Intel Z77 chipset: 2 x SATA 6Gb/s port(s), gray; 4 x SATA 3Gb/s port(s), blue; Support Raid 0, 1, 5, 10; Supports Intel Smart Response Technology, Intel Rapid Start Technology, Intel Smart Connect Technology |
| Видео |
Multi-VGA output support: HDMI/DVI/RGB ports; Supports HDMI with max. resolution 1920 x 1200 @ 60 Hz; Supports DVI with max. resolution 1920 x 1200 @ 60 Hz; Supports RGB with max. resolution 2048 x 1536 @ 75 Hz; Maximum shared memory of 1696 MB; Supports |
| Аудио |
Realtek ALC887 8-Channel High Definition Audio CODEC; Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking; Audio Feature: Optical S/PDIF out port(s) at back panel |
| LAN |
Realtek 8111E, 1 x Gigabit LAN Controller(s) |
| BIOS |
64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.7, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3, F12 PrintScreen, F3 Shortcut Function and ASUS DRAM SPD (Serial Presence Detect) memory information |
| Форм фактор |
ATX; 30.5 cm x 21.8 cm |
| Гаранционен срок |
36 месеца |
