| Чипсет |
Intel Z77 |
| Съвместими процесори |
Intel Socket 1155 for 3rd/2nd Generation Processors; Supports Intel 22 nm CPU; Supports Intel 32 nm CPU; Supports Intel Turbo Boost Technology 2.0 |
| Памет |
4 x DIMM, Max. 32GB, DDR3 MHz Non-ECC, Un-buffered Memory; Dual Channel Memory Architecture; Supports Intel Extreme Memory Profile (XMP) |
| Портове |
1 x PS/2 keyboard/mouse combo port(s); 1 x DVI-D; 1 x D-Sub; 1 x DisplayPort; 1 x HDMI; 1 x LAN (RJ45) port(s); 4 x USB 3.0; 2 x USB 2.0; 1 x Optical S/PDIF out; 6 x Audio jack(s); 1 x WLAN connector(s) for ASUS wireless module |
| Слотове |
2 x PCIe 3.0/2.0 x16 (x16 or dual x8); 1 x PCIe 2.0 x16 (x4 mode, black); 2 x PCIe 2.0 x1; 2 x PCI; Supports NVIDIA Quad-GPU SLI Technology; Supports AMD Quad-GPU CrossFireX Technology; Supports AMD 3-Way CrossFireX Technology |
| Дисков интерфейс |
Intel Z77 chipset: 2 x SATA 6Gb/s port(s), gray; 4 x SATA 3Gb/s port(s), blue; Support Raid 0, 1, 5, 10; Supports Intel Smart Response Technology, Intel Rapid Start Technology, Intel Smart Connect Technology |
| Видео |
Multi-VGA output support : HDMI/DVI/RGB/DisplayPort ports; Supports Intel HD Graphics, InTru 3D, Quick Sync Video, Clear Video HD Technology, Insider |
| Аудио |
Audio Feature: Absolute Pitch 192kHz/ 24-bit True BD Lossless Sound; DTS Ultra PC II; DTS Connect; Optical S/PDIF out port(s) at back panel |
| LAN |
Intel 82579V, 1 x Gigabit LAN Controller(s); Intel LAN- Dual interconnect between the Integrated LAN controller and Physical Layer (PHY); Wireless Data Network: Wi-Fi 802.11 b/g/n; Supports single band frequency 2.4GHz |
| BIOS |
64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.5, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3, F12 PrintScreen, F3 Shortcut Function and ASUS DRAM SPD (Serial Presence Detect) memory information |
| Форм фактор |
ATX |
| Други |
Dimensions 30.5 cm x 24.4 cm |
| Гаранционен срок |
36 месеца |
