Характеристики
Характеристики
| Описание | Audio Performance: Output Signal-to-Noise Ratio (A-Weighted): 116dB for front-out, 112dB for other channels dB, Input Signal-to-Noise Ratio (A-Weighted): 112 dB, Output THD+N at 1kHz: 0.00056% (-105dB) for Front-out, Input THD+N at 1kHz: 0.0004% (-108dB) for Line-in, Frequency Response (-3dB, 24-bit/96kHz input): <10Hz to 48KHz, Output/Input Full-Scale Voltage 2 Vrms (5.65 Vp-p); Main Chipset: Audio Processor: ASUS AV100 High-Definition Sound Processor (Max. 192KHz/24bit), 24-bit D-A Converter of Digital Sources: Cirrus-Logic CS4398*1 for Front-Out (120dB SNR, Max. 192kHz/24bit), Cirrus-Logic, CS4362A*1 for other 6 channels (114dB SNR, Max. 192kHz/24bit), 24-bit A-D Converter for Analog Inputs: Cirrus-Logic CS5361* 1 (114dB SNR, Max. 192kHz/24bit); Sample Rate and Resolution: Analog Playback Sample Rate and Resolution: 4.1K/48K/96K/192KHz @ 16/24bit, Analog Recording Sample Rate and Resolution: 44.1K/48K/96K/192KHz @ 16/24bit, S/PDIF Digital Output: 44.1K/48K/96K/192KHz @ 16/24bit, Dolby Digital, DTS, S/PDIF Digital Input: 44.1K/48K/96K/192KHz @ 16/24bit, ASIO 2.0 Driver Support: Supports 44.1K/48K/96K/192KHz @16/24bit with very low latency; I/O Ports: Analog Output Jack: 3.50mm mini jack *4 (Front/Side/Center-Subwoofer/Back), Analog Input Jack: 3.50mm mini jack *1 (Shared by Line-In/Mic-In), Other line-level analog input (for CD-IN/TV Tuner): Aux-In (4-pin header on the card), Digital S/PDIF Output: High-bandwidth TOS-Link optical transmitter (shared with Line-In/Mic-In jack) supports 192KHz/24bit, S/PDIF Header: Connecting to supported VGA cards with HDMI output; |
|---|---|
| Гаранционен срок | 36 месеца |
