Характеристики
Характеристики
| Описание | • Audio Interface PCI Express • Audio Performance Output Signal-to-Noise Ratio (A-Weighted) (Front-out) : 118 dB Output Signal-to-Noise Ratio (A-Weighted) (Headphone-out) : 118 dB Output THD+N at 1kHz (Front-out) : >0.0004 %(-108 dB) Frequency Response (-3dB, 16bit/44.1KHz input) : 10 Hz to 46 KHz Output/Input Full-Scale Voltage : Unbalanced Output : 2 Vrms (5.65 Vp-p) • Chipset Audio Processor :ASUS AV200 High-Definition Sound Processor (Max. 192KHz/24bit) • Sample Rate and Resolution Analog Playback Sample Rate and Resolution : 44.1K/48K/88.2K/96K/176.4K/192KHz @ 16bit/24bit Analog Recording Sample Rate and Resolution : 44.1K/48K/88.2K/96K/176.4K/192KHz @ 16bit S/PDIF Digital Output : 44.1K/48K/88.2K/96K/176.4K/192KHz @ 16bit/24bit S/PDIF Digital Input : 44.1K/48K/88.2K/96K/176.4K/192KHz @ 16bit/24bit ASIO Driver Support : 44.1K/48K/88.2K/96K/176.4K/192KHz @ 16bit/24bit • Connectivity Analog Output 4 x 3.5 mm jack (1/8") (Front out/Side out/Center-Subwoofer out/Rear out) Analog Input 2 x 3.5 mm jack (1/8") (Line-in/Mic-in) Digital 1 x S/PDIF out (1 x Coaxial) 1 x S/PDIF in (1 x Coaxial) 1 x MIDI in/out 1 x Aux in (4-pin header) • Special Features Dolby Technologies : Dolby Digital Live/Dolby Headphone /Dolby Virtual Speaker /Dolby Pro-Logic II DTS Technologies : DTS Interactive Encoder/DTS Neo:PC technologies • Accessories H6 extension board cable x 1 DVI-to-HDMI cable x 1 HDMI-to-HDMI cable x 1 S/PDIF adaptor x 2 3.5mm-to-RCA adaptor cable (8-ch) x 4 Additional MIDI card, cable, and external standard MIDI adaptor Y cable x 1 Quick Start Guide x 1 • Note Bundled software: ● Ableton Live 6 Lite ● PowerDVD 7.0 ● Valuable Cakewalk Sonar LE, Dimesion LE, and Project5 LE |
|---|---|
| Гаранционен срок | 36 месеца |
