Характеристики
Характеристики
| Чипсет | Intel Z170 |
|---|---|
| Съвместими процесори | Intel Socket 1151 for 6th Generation Core i7/Core i5/Core i3/Pentium/Celeron Processors, Supports Intel 14 nm CPU, Supports Intel Turbo Boost Technology 2.0 |
| Памет | 2 x DIMM, Max. 32GB, DDR4 3400(O.C.)/3333(O.C.)/3200(O.C.)/3100(O.C.)/3000(O.C.)/2933(O.C.)/2800(O.C.)/2666(O.C.)/2600(O.C.)/2400(O.C.)/2133 MHz Non-ECC, Un-buffered Memory, Dual Channel Memory Architecture, Supports Intel Extreme Memory Profile (XMP) |
| Портове | 1 x PS/2 keyboard/mouse combo port(s), 1 x DisplayPort, 1 x HDMI, 1 x LAN (RJ45) port(s), 2 x USB 3.1 (red)Type-A, 4 x USB 3.0, 2 x USB 2.0, 1 x Optical S/PDIF out, 5 x Audio jack(s), 2 x Wi-Fi antenna port(s) |
| Слотове | 1 x PCIe 3.0/2.0 x16 |
| Конектори | 1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s) (19-pin); 1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s); 1 x SATA Express connector: gray, Compatible with 2 x SATA 6.0 Gb/s ports; 1 x M.2 Socket 3 with M Key design, type 2242/2260/2280 storage devices support (Supports both SATA & PCIE SSD); 2 x SATA 6Gb/s connector(s); 1 x CPU Fan connector(s) (1 x 4 -pin); 2 x Chassis Fan connector(s) (2 x 4 -pin); 1 x 24-pin EATX Power connector(s); 1 x 8-pin ATX 12V Power connector(s); 1 x Front panel audio connector(s) (AAFP); 1 x System panel(s); 1 x Clear CMOS jumper(s); 1 x 14-1 pin TPM connector; |
| Дисков интерфейс | Support Raid 0, 1, 5, 10, Intel Rapid Storage Technology supports 1 x SATA Express port, Compatible with 2 x SATA 6.0 Gb/s ports, 1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (both SATA & PCIE mode), 2 x SATA 6Gb/s port(s), Su |
| Видео | Integrated Graphics Processor- Intel HD Graphics support Multi-VGA output support: HDMI/DisplayPort ports, Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz, Supports DisplayPort with max. resolution 4096 x 2304 @ 60 Hz, Maximum shared memory of 1024 |
| Аудио | SupremeFX 8-Channel High Definition Audio CODEC, Supports: Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking, High quality 115 dB SNR stereo playback output, Audio Feature: SupremeFX Shielding Technology, Optical S/PDIF out port(s) at back p |
| LAN | Intel I219V, 1 x Gigabit LAN Controller(s), GameFirst technology Anti-surge LANGuard |
| BIOS | 128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0 ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Quick Note, Last Modified log, F12 PrintScreen, and ASUS DRAM SPD ( |
| Форм фактор | Mini ITX Form Factor 6.7 inch x 6.7 inch (17 cm x 17 cm) |
| Аксесоари | User's manual, ASUS Q-Shield, M.2 2242 mounting kit, 4 x SATA 6Gb/s cable(s), 1 x M.2 Screw Package, 1 x CPU installation tool, 1 x Supporting DVD, 1 x 12 in 1 Cable Label (s) |
| Гаранционен срок | 36 месеца |
