| Чипсет |
Intel Z87 |
| Процесор |
Intel Socket 1150 for 4th Generation Core i7/Core i5/Pentium/Celeron Processors, Supports Intel 22 nm CPU, Supports Intel Turbo Boost Technology 2.0 |
| Памет |
4 x DIMM, Max. 32GB, DDR3 3000(O.C.)/2933(O.C.)/2800(O.C.)/2666(O.C.)/2600(O.C.)/2500(O.C.)/2400(O.C.)/2200(O.C.)/2133(O.C.)/2000(O.C.)/1866(O.C.)/1800(O.C.)/1600/1333 MHz Non-ECC, Un-buffered Memory, Dual Channel Memory Architecture, Supports Intel® Extr |
| Multi-GPU Support |
Supports NVIDIA® Quad-GPU SLI Technology *2, Supports AMD Quad-GPU CrossFireX Technology |
| Портове |
USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s) (19-pin), 4 x USB 2.0 connector(s) support(s) additional 8 USB 2.0 port(s), TPM header, 8 x SATA 6Gb/s connector(s), CPU Fan connector(s) (1 x 4 -pin), CPU OPT Fan connector(s) (1 x 4 -pin) |
| Слотове |
2 x PCIe 3.0/2.0 x16 (x16 or dual x8) , 1 x PCIe 2.0 x16 (x2 mode) , 2 x PCIe 2.0 x1, 2 x PCI |
| Дисков интерфейс |
Intel Z87 chipset : 6 x SATA 6Gb/s port(s), yellow, Support Raid 0, 1, 5, 10, Supports Intel Dynamic Storage Accelerator, Intel Smart Response Technology, Intel Rapid Start Technology, Intel Smart Connect Technology*3, ASMedia ASM1061 controller : *4, 2 |
| Видео |
Integrated Graphics Processor , Multi-VGA output support : HDMI/DVI-D/RGB/Mini DisplayPort ports *1,- Supports HDMI with max. resolution 4096 x 2160 @ 24 Hz / 2560 x 1600 @ 60 Hz, - Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz, - Supports RGB |
| Аудио |
Realtek ALC892 8-Channel High Definition Audio CODEC, - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking |
| LAN |
Intel I217V, 1 x Gigabit LAN Controller(s), Intel LAN- Dual interconnect between the Integrated LAN controller and Physical Layer (PHY) |
| BIOS |
64 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.7, WfM2.0, SM BIOS 2.7, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3, My Favorites, Quick Note, Last Modified log, F12 PrintScreen, F3 Shortcut functions, and ASUS DRAM SPD (Serial Presen |
| Форм фактор |
ATX Form Factor, 12 inch x 9.2 inch ( 30.5 cm x 23.37 cm ) |
| Аксесоари |
User's manual, I/O Shield, 3 x SATA 6Gb/s cable(s), SLI bridge(s), Q-connector(s) (2 in 1) |
| Други |
ASUS Dual Intelligent Processors 4 with 4-Way Optimization, ASUS 5X Protection, ASUS EPU, ASUS Digital Power Design, ASUS Exclusive Features, ASUS Quiet Thermal Solution, ASUS EZ DIY, ASUS Q-Design, 100% All High-quality Conductive Polymer Capacitors Over |
| Гаранционен срок |
36 месеца |
