Характеристики
Характеристики
| Описание | • Console Connectors (connect to keyboard, mouse, monitor) - Keyboard connector: mini DIN-6 PIN female - Mouse connector: mini DIN-6 PIN female - Monitor connector: HD 15 PIN female • KVM Cables With Connectors (connect to computers) - 2 cables each 1.8 meter (6 feet) long attached to KVM switch - 2 keyboard connectors: mini DIN-6 PIN male - 2 mouse connectors: mini DIN-6 PIN male - 2 monitor connectors: HD 15 PIN male • Diagnostic LEDs - 2 port LEDs for 2 connected PCs - A lit (green) status indicates the port is active • PC Selection (Manually switching back and forth between 2 PCs) - Through Push buttons - Through Hot Key - Switching confirmation: buzzer sound • Power Voltage 5V 1A • Power Input From PC's PS2 port, no power adapter required • Power Consumption 5V 70mA • Dimensions 104 x 62 x 28 mm (KVM switch only) • Weight 420 grams (KVM switch & 2 sets of KVM cables) • Operating Temperature 0o t o 40oC • Storage Temperature -20o to 60o C • Operating Humidy 0% to 80% • Storage Humidity 0% to 80% • Emission (EMI) - FCC Class B - CE Class B - C-Tick |
|---|---|
| Гаранционен срок | 24 месеца |
