| Чипсет |
North Bridge: AMD 760G; South Bridge: AMD SB710 |
| Съвместими процесори |
Support for AMD AM3+ processor; Support for AMD AM3 Phenom II processor / AMD Athlon II processor |
| Памет |
4 x 1.5V DDR3 DIMM sockets supporting up to 32 GB of system memory (Note 1); Dual channel memory architecture; Support for 1333+ (O.C.)/1066 MHz memory modules |
| Портове |
1 x PS/2 keyboard/mouse port; 1 x D-Sub port; 1 x DVI-D port; 4 x USB 2.0/1.1 ports; 1 x RJ-45 port; 3 x audio jacks (Line In, Line Out, Mic In) |
| Слотове |
1 x PCI Express x16 slot, running at x16; 1 x PCI Express x1 slot; 1 x PCI slot |
| Дисков интерфейс |
1 x IDE connector supporting ATA-100/66/33 and up to 2 IDE devices; 6 x SATA 3Gb/s connectors; Support for RAID 0, RAID 1, RAID 10, and JBOD |
| Аудио |
VIA VT2021 codec; High Definition Audio; 2/4/5.1/7.1-channel (Note 3); Support for S/PDIF Out |
| LAN |
Realtek GbE LAN chip (10/100/1000 Mbit) |
| BIOS |
2 x 32 Mbit flash; Use of licensed AWARD BIOS; Support for DualBIOS; PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b |
| Форм фактор |
Micro ATX Form Factor |
| Други |
24.4cm x 24.4cm |
| Гаранционен срок |
36 месеца |
