| Чипсет |
North Bridge: AMD 970, South Bridge: AMD SB950 |
| Процесор |
AMD AM3+ FX processors, AMD AM3 Phenom II processor/ AMD Athlon II processor |
| Памет |
4 x 1.5V DDR3 DIMM sockets supporting up to 32 GB of system memory (Note 1), Dual channel memory architecture, Support for DDR3 2000(O.C.)/1866/1600/1333/1066 MHz memory modules (Note 2), Support for Extreme Memory Profile (XMP) memory modules |
| Портове |
Up to 14 USB 2.0/1.1 ports, Up to 4 USB 3.0/2.0 ports, PS/2 keyboard/mouse port, optical S/PDIF Out connector, 8 x USB 2.0/1.1 ports, 2 x USB 3.0/2.0 ports, RJ-45 port, 6 x audio jacks |
| Слотове |
PCI Express x16 slot, running at x16 (PCIEX16) (Note 3), PCI Express x16 slot, running at x4 (PCIEX4), 3 x PCI Express x1 slots, 2 x PCI slots |
| Дисков интерфейс |
6 x SATA 6Gb/s connectors supporting up to 6 SATA 6Gb/s devices, Support for RAID 0, RAID 1, RAID 5, RAID 10, and JBOD |
| Аудио |
VIA VT2021 codec, High Definition Audio, 2/4/5.1/7.1-channel, Support for S/PDIF Out |
| LAN |
Realtek GbE LAN chip (10/100/1000 Mbit) |
| BIOS |
2 x 32 Mbit flash, Use of licensed AMI EFI BIOS, Support for DualBIOS, PnP 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a |
| Форм фактор |
ATX |
| Други |
Dimensions 30.5cm x 22.4cm |
| Гаранционен срок |
36 месеца |
