| Чипсет |
6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers), Integrated in the APU: 2 x USB 3.0/2.0 ports on the back panel |
| Процесор |
AMD Athlon series processors, AMD Sempron series processors |
| Съвместими процесори |
AMD Athlon series processors, AMD Sempron series processors |
| Памет |
2 x 1.5V DDR3 DIMM sockets supporting up to 32 GB of system memory, Support for DDR3 1600/1333 MHz memory modules, Support for Extreme Memory Profile (XMP) memory modules |
| Портове |
2 x USB 2.0/1.1 ports, 2 x USB 3.0/2.0 ports, 1 x RJ-45 port, 3 x audio jacks (Line In, Line Out, Mic In), 1 x D-Sub port, 1 x parallel port, 1 x PS/2 keyboard port, 1 x PS/2 mouse port, 1 x serial port |
| Слотове |
1 x PCI Express x16 slot, running at x4 (PCIEX4), 1 x PCI Express x1 slot , (The PCI Express slots conform to PCI Express 2.0 standard.), 1 x PCI slot |
| Дисков интерфейс |
2 x SATA 6Gb/s connectors |
| Видео |
1 x D-Sub port, supporting a maximum resolution of 1920x1200, Maximum shared memory of 2 GB |
| Аудио |
Realtek ALC887 codec, High Definition Audio, 2/4/5.1/7.1-channel, *To configure 7.1-channel audio, you have to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver., Support for S/PDIF Out |
| LAN |
Realtek GbE LAN chip (10/100/1000 Mbit) |
| BIOS |
2 x 32 Mbit flash, Use of licensed AMI UEFI BIOS, Support for DualBIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Форм фактор |
Micro ATX Form Factor; 22.6cm x 17.0cm |
| Други |
Support for @BIOS, Support for Xpress Install, Support for Smart Recovery 2, Support for EasyTune, * Available functions in EasyTune may differ by motherboard model., Support for Q-Flash, Support for ON/OFF Charge |
| Гаранционен срок |
36 месеца |
