| Чипсет |
Intel B75 Express Chipset |
| Съвместими процесори |
Support for Intel Core i7 processors/Intel Core i5 processors/ Intel Core i3 processors/Intel Pentium processors/Intel Celeron processors in the LGA1155 package, L3 cache varies with CPU |
| Памет |
2 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory; Dual channel memory architecture; Support for DDR3 1600/1333/1066 MHz memory modules; Support for non-ECC memory modules; Support for Extreme Memory Profile (XMP) memory modules |
| Портове |
1 x PS/2 keyboard/mouse port; 1 x D-Sub port; 1 x DVI-D port; 1 x HDMI port; 2 x USB 3.0/2.0 ports; 4 x USB 2.0/1.1 ports; 1 x RJ-45 port; 3 x audio jacks (Line In/Line Out/Microphone) |
| Слотове |
1 x PCI Express x16 slot, running at x16; (The PCI Express x16 slot conforms to PCI Express 3.0 standard.); 2 x PCI Express x1 slots (All PCI Express x1 slots conform to PCI Express 2.0 standard.); 1 x PCI slot |
| Дисков интерфейс |
1 x SATA 6Gb/s connector (SATA3 0) supporting up to 1 SATA 6Gb/s device, 5 x SATA 3Gb/s connectors (SATA2 1~5) supporting up to 5 SATA 3Gb/s devices |
| Видео |
1 x D-Sub port, 1 x DVI-D port, supporting a maximum resolution of 1920x1200 |
| Аудио |
Realtek ALC887 codec; High Definition Audio; 2/4/5.1/7.1-channel |
| LAN |
Realtek GbE LAN chip (10/100/1000 Mbit) |
| BIOS |
2 x 32 Mbit flash, Use of licensed AMI EFI BIOS, Support for DualBIOS, PnP 1.0a, DMI 2.0, SM BIOS 2.6, ACPI 2.0a |
| Форм фактор |
Micro ATX |
| Други |
Dimensions 24.4cm x 17.4cm |
| Гаранционен срок |
36 месеца |
