Характеристики
Характеристики
| Чипсет | Intel B85 Express Chipset |
|---|---|
| Съвместими процесори | Support for Intel Core i7 processors/Intel Core i5 processors/ Intel Core i3 processors/Intel Pentium processors/ Intel Celeron processors in the LGA1150 package |
| Памет | 2 x DDR3 DIMM sockets supporting up to 16 GB of system memory, Dual channel memory architecture, Support for DDR3 1600/1333 MHz memory modules, Support for non-ECC memory modules, Support for Extreme Memory Profile (XMP) memory modules |
| Портове | 1 x PS/2 keyboard/mouse port,1 x parallel port, 1 x D-Sub port, 1 x DVI-D port, 2 x USB 3.0/2.0 ports, 4 x USB 2.0/1.1 ports, 1 x RJ-45 port, 3 x audio jacks (Line In, Line Out, Mic In) |
| Слотове | 1 x PCI Express x16 slot, running at x16; 2 x PCI Express x1 slots; 1 x PCI slot |
| Конектори | 1 x 24-pin ATX main power connector; 1 x 8-pin ATX 12V power connector; 4 x SATA 6Gb/s connectors; 2 x SATA 3Gb/s connectors; 1 x CPU fan header; 1 x system fan header; 1 x front panel header; 1 x front panel audio header; 1 x USB 3.0/2.0 header; 2 x USB 2.0/1.1 headers; 1 x serial port header; 1 x Clear CMOS jumper |
| Дисков интерфейс | 4 x SATA 6Gb/s connectors (SATA3 0/1/2/3), 2 x SATA 3Gb/s connectors (SATA2 4/5) |
| Видео | Integrated Graphics Processor - Intel HD Graphics support: 1 x D-Sub port, supporting a maximum resolution of 1920x1200, 1 x DVI-D port, supporting a maximum resolution of 1920x1200, Maximum shared memory of 1 GB |
| Аудио | Realtek ALC887 codec, High Definition Audio, 2/4/5.1/7.1-channel |
| LAN | Realtek GbE LAN chip (10/100/1000 Mbit) |
| BIOS | 2 x 32 Mbit flash, Use of licensed AMI UEFI BIOS, Support for DualBIOS, PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Форм фактор | Micro ATX Form Factor; 24.4cm x 17.4cm |
| Гаранционен срок | 36 месеца |
